• Model NO.：ZE480E(sp)
• Drive Type：Electric Drive
• Bucket Capacity：2.15cbm
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Mass：47500kg
• Swing Speed：32.4,35.3r,Min
• Maximum Drawbar Pull：350kn
• Bucket Digging Force(ISO)：215kn
• Gradeablity：35
• Travel Speed (High / Low)：3.2,5.4km,H
• Engine Manufacturer：Cumins
• Rated Power：274,1800 Kw,Rpm
• System Flow：34.3,37MPa
• Slewing Speed(Rpm)：8.5
• Transport Package：Container,RO-RO
• Specification：2800*2800*3200mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：8429521200
• Production Capacity：100,Month

Basic Info.

Model NO. ZE480E(sp) Drive Type Electric Drive Bucket Capacity 2.15cbm Size Small-Scale Certification CE, ISO9001: 2000 Condition New Operating Mass 47500kg Swing Speed 32.4/35.3r/Min Maximum Drawbar Pull 350kn Bucket Digging Force(ISO) 215kn Gradeablity 35 Travel Speed (High / Low) 3.2/5.4km/H Engine Manufacturer Cumins Rated Power 274/1800 Kw/Rpm System Flow 34.3/37MPa Slewing Speed(Rpm) 8.5 Transport Package Container/RO-RO Specification 2800*2800*3200mm Trademark ZOOMLION Origin China HS Code 8429521200 Production Capacity 100/Month

Product Description

Zoomlion 35ton Digger Machine Excavators  ZE365E  with High Quality for Sale

Product Description
ZE480E/ZE480Esp are equipped with electronically controlled imported CUMINS engines (EURO II emission standard), which deliver maximum reliability due to its powerful and robust design.

Top-quality key hydraulic parts from famous brands are reliable, energy-saving and high-efficient. Work equipment and carriage in strengthened design can adapt the excavator to all kinds of harsh working conditions.

The new-generation smart control system delivers high work efficiency with reduced fuel consumption. Thanks to the new noise-reducing and shock-absorbing technologies, lowered noise and reduced vibration can be guaranteed.

A high level of operator comfort can be ensured thanks to the spacious, comfortable, low-noise and low-vibration cab that offers plenty of room, as well as full-automatic air conditioner (cool & warm), all-dimensionally adjustable suspension seat and movable armrest in the cab.

The smart color multi-functional LCD monitor with super-large screen ensures easy monitoring of machine working conditions. Aesthetic and smooth appearance with modernity and three-dimensional appeal brings stronger and more robust machine.

Keeping advantages of ZE480E, ZE480Esp adopts reinforced short arm and short stick, as well as optional larger-capacity bucket. As a result, boom digging force and stick digging force have been significantly improved, which is more advantageous to mining operation.

ZE485E-10 is equipped with imported CUMMINS engine which satisfies EURO III emission standard. The powerful and robust engine with sufficient power reserve is energy-saving and environment-friendly. ZE485E-10 further improves its structural parts by adopting integrally-formed large-profile design, which reduces butt welding via reduced stress and meanwhile strengthens & thickens key locations, thus bringing stronger load bearing capacity. Heavy-duty components such as bearing, sprockets and track rollers have been exclusively strengthened. Plates for key locations are thickened by adopting imported wear-resistant steel plate. The machine adopts mine-type lengthened and widened undercarriage and track. Beyond that, it is equipped with reinforced platform and work equipment. Control valve element and electrically controlled system for the hydraulic pump have been further upgraded, indicating smoother control, higher efficiency and more excellent energy-saving performance.
Parameter

Item	ZE480E	ZE480Esp
Operating Weight(kg)	47500	47400
Rated power(kW/rpm)	274/1800	274/1800
Standard bucket capacity(SAE)(M3)	2.15	2.65
System flow	34.3/37Mpa	34.3/37Mpa
Engine model	Cumins QSM11	Cumins QSM11
Traveling speed(low/high)(km/h)	3.2/5.4	3.2/5.4
Slewing speed(rpm)	8.5	8.5
Gradeablity	35°	35°
Max. drawbar pull(kN)	350	350
