• Model NO.：SD26
• Engine Power：147~515kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Transport Package：Nude Package
• Specification：23400Kg
• Trademark：SHANTUI
• Origin：China
• HS Code：84291190
• Production Capacity：500unit,Month

Basic Info.

Model NO. SD26 Engine Power 147~515kw Certification CE, ISO9001: 2000 Condition New Color Yellow Transport Package Nude Package Specification 23400Kg Trademark SHANTUI Origin China HS Code 84291190 Production Capacity 500unit/Month

Product Description

SHANTUI SD26 Bulldozer Easy maintenances

  - The structural parts inherit the excellent quality of Shan.tui mature products.

  - The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.

  - The openable large-space side hoods make the repairs and maintenance easier.

  - All lubricating and maintenance points of machine are directed to the outer side of machine body to achieve convenient and rapid maintenances.

 Working adaptability  - S's mature product chassis system is applicable to diversified severe working conditions, featuring high stability and reliability.

 - Long ground length, high ground clearance, stable driving, and good trafficability.

 - The straight tilting blade, semi-U blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.

 Driving/Riding Environment

 - The hexahedral cab provides super-large interior space and broad viision and the ROPS/FOPS can be installed depending on specific needs to ensure high safety and reliability.

 - The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.


Parameter name	SD26	SD26E(LONG TRACK)	SD26F(FOREST LOGGING)	SD26S(LGP)
Performance parameters
Operating weight (Kg)	23400	24600	24700	25700
Ground pressure (kPa)	77	72	66	41
Engine
Engine model	WEICHAI WP12	WEICHAI WP12	WEICHAI WP12	WEICHAI WP12
Rated power/rated speed (kW/rpm)	206/1800	206/1800	206/1800	206/1800
Overall dimensions
Overall dimensions of machine (mm)	5495*3725*3402	5495*3725*3402	5495*3725*3402	6225*4365*3402
Driving performance
Forward speed (km/h)	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7
Reversing speed (km/h)	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9
Chassis System
Center distance of track (mm)	2000	2000	2000	2250
Width of track shoes (mm)	560	560	560	910
Ground length(mm)	2730	3050	2730	3480
Tank capacity
Fuel tank (L)	450	450	450	450
Working device
Blade type	Straight-tilt	Straight-tilt	Straight-tilt	Straight-tilt
Ripper type	Single shank/3 shanks	Single shank/3 shanks	Single shank/3 shanks	--
Ripping depth (mm)	695/666	695/666	695/666	--
