• Certification：ISO9001: 2000
• Condition：Used
• Color：Yellow
• Trademark：CAT
• Origin：China

EngineModel & type

Shangchai SC11CB184G2B1/Weichai WD10G178E25;

water-cooled, in-line, 4-stroke injection direct

Horsepower

Gross power: 131/175/1850 kW/HP/rpm //

Net power: 120/160/1850 kW/HP/rpm

Number of cylinders 6-126 x 130 mm (bore x stroke)Piston displacement 9.726 LMin. fuel consumption 214 g/kW·hMaximum torque765 N·m@1300 rpm

Power

 transmission

 system

Torque converter 3-element, 1 stage, 1 phaseTransmission Planetary gear type, power-shift, forced lubricationMain drive

Spiral bevel gear, single-stage speed reduction,

splash lubrication

Steering clutch

Lubricated, multi-disc, spring loaded, hand hydraulically separated, inter-linking with steering brake

Steering brake

Lubricated, floating band structure, foot brake

with hydraulic booster

Final drive2-stage speed reduction of spur gear, splash lubricationTravel speedGear 1st2nd 3rdForward0~3.29 km/h 0~5.82 km/h0~9.63 km/hReverse0~4.28 km/h0~7.59 km/h0~12.53 km/hUndercarriage
 systemTypeSprayed beam, suspended structure of equalizerCarrier rollers2 each sideTrack rollers6 each sideTrack type Assembled, single-grouserWidth of track shoes 510 mmPitch 203.2 mmHydraulic
SystemMaximum pressure 14 MPaPump type Gear pumpDischarge 243 L/min

Bore of

working cylinder × no.

110 mm × 2BladeBlade TypeStraight-tiltAngleU- BladeDozing capacity 4.5 m 3 4.4 m 35.0 m 3

Efficiency

(Theoretical value 40 m)

225 m 3 /h225 m 3 /h250 m 3 /hBlade width3388 mm3970 mm 3556 mmBlade height1149 mm 1040 mm1120 mm

Maximum drop

below ground

540 mm530 mm540 mmLifting height of blade1095 mm 1110 mm 1095 mmRiipper
(Optional)

Maximum digging depth

of 3-shank ripper

572 mm

Maximum lift

above ground

592 mmWeight of 3-shank ripper 1667 kg






Service

Pre-sales service

1, 24 hours online .Your inquiry will be quick reply  by email .
 Also can go through all questions with you by any online chatting tools
2,Professionally and patiently introduction,details pictures and working video to show machine .
3,Visting our factory.

Service on sales

1,Test every machine and inspect the machine seriously .
2,Send the machine picture which you order , then packing it with standard export package after you confirm the machine is ok .
3,Delivery:If ship by sea .after delivery to seaport .Will tell you the shipping time and arrival time . Finally, send all original documents to you by Express. We will tell you the tracking number after we post the documents.

After-sales service

1, 24 hours online to solve any problem . Supply you English manual book and technical support , maintain and install video to help you solve the problem, or dispatch worker to your factory.
2 Training how to install the machine, training how to use, maintain and repair the machine.

FAQ

1,What is the voltage/phase for this machine ?
220V 50Hz/single phase ,380V 50Hz/three phase .We also could produce according to customer's requirement.
2.What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. We will show you the photos of the products and packages before you pay the balance.
3.What your terms of delivery?
EXW,FOB,CFR,CIF,DAF.
4.How about your delivery time?
Generally, it will take about 13 days after receipt of deposit payment. The specific delivery time depends on the items and the quantity of your order.
5 ,What's your MOQ?
1 set
6, How should I do if meet some trouble while using?
We can supply English manual book and also take a video for showing how to resolve the problems
or dispatch our worker to your factory.
