• Model NO.：BMRW
• Specification：cast iron
• Trademark：hanjiu
• Origin：China
• HS Code：841229100
• Production Capacity：500000

TYPEBMR-50
BMRW-50
BMRS-50BMR-80
BMRW-80
BMRS-80BMR-100
BMRW-100
BMRS-100BMR-125
BMRW-125
BMRS-125BMR-160
BMRW-160
BMRS-160BMR-200
BMRW-200
BMRS-200BMR-250
BMRW-250
BMRS-250BMR-315
BMRW-315
BMRS-315BMR-400
BMRW-400
BMRS-400
Displacement  (ml/r)51.780.5100.5126.3160.8200.9252.6321.5401.9Max.Pressure.Drop(Mpa)cont.1414141414141197int.17.517.517.517.517.517.514119peak.202020202020161311Max.Torque(N.m)cont.93152194237310369380380380int.118189236296378450470470470peak.135216270338433509540540540Speed.Range(cont.)(r/min)10-77510-75010-60010-47510-37510-30010-24010-19010-160Max.Flow(cont.)(L/min)406060606060606060Max.Output.Power(cont.)(Kw)7101010108654eight(kg)6.56.97.07.37.58.08.59.011






Application

Shijiazhuang Hanjiu Technology Co.,Ltd
A hydraulic motor, which is an actuator of a hydraulic system, converts hydraulic pressure energy supplied by a hydraulic pump into the mechanical energy (torque and rotational speed) of its output shaft. Hydraulic motors, also known as oil motors, are mainly used in injection molding machinery, ships, hoists, construction machinery, construction machinery, coal mining machinery, mining machinery, metallurgical machinery, shipbuilding machinery, petrochemicals, and port machinery.

• Cone Splitter

• Excavator Splitter

• Drilling Machine

• Mining Equipment

• Geological exploration

Shijiazhuang Hanjiu Technology Co., Ltd. is a professional manufacturer of BM series cycloidal hydraulic motors and BZZ steering gears. Our factory has dozens of highly qualified and professional engineers and technicians, and introduced many advanced machines in 2010. The production facilities are large-scale factories in northern China and produce more than 300,000 units each year.
  Our factory specializes in designing and producing any type of motor and steering gear required by our customers, from large to small, from low to high displacement. And can replace Danfoss, Eaton, M + S series models. Products are widely used in engineering machinery, mining machinery, metallurgical machinery, petroleum machinery, agricultural machinery, injection molding machinery, fishery machinery and other fields.
  My factory takes honesty first and quality first as its tenet. From the employees' posts to the raw materials, to the factory, from parts processing and assembly advice to product leaving, there is a relatively complete product quality system. And passed CE certification. Our factory is committed to establishing an internationally renowned brand and looks forward to long-term cooperation with more demanders of hydraulic products.







Please do not hesitate to contact us for further information, inquiries or orders.
Thank you for choosing 'Hanjiu' Hydraulics.
