Swamp Buggy with Aluminum Track

Sinoway Industrial (Shanghai) Co., Ltd.

Type：Crawler Excavator
Usage：Special Excavator, Marine Excavator, Mining Excavator
Bucket：Backhoe
Transmission：Hydraulic Transmission
Drive Type：Internal Combustion Drive
Bucket Capacity：1.0~1.5m³

Base Info

Model NO.：SWEA220
Size：Large-Scale
Certification：ISO9001: 2000, ISO14001
Condition：New
Engine：Doosan
Hydraulic System：Doosan
Operating Weight：41.5 Ton
Chain Number：Three
Boom Length：15 M
Warranty：One Year
Transport Package：Nude
Specification：ISO2008
Trademark：SINOWAY
Origin：China
HS Code：84294090
Production Capacity：100 PCS , Year

Description

Engine ModelCummins/IsuzuTypeSix-cylinder,water-cooled turbocharged,mechanical injectionRated power106~125KWRated speed2100rpmMain Technical Specification Operating weight30000~42000KgStandard bucket capacity0.5~1.1m³Slewing speed 11rpm11rpmStick digging force110KNBucket digging force150KNMain Features Tracked pontoon structure Big torque travelling device Big circular arc structure High capacity of fuel tank Main Applications River/Beach earth moving Swamp works Dredging applications Delta works Waterway deepening Hydraulic System Main pumpKAWASAKIMain valveKAWASAKIMotorKAWASAKIHydraulic flow rate2x235L/minHydraulic pressure32MPaTravelling System Travelling speed0~5.4km/hGrade ability65%Ground pressure0.0135MPaNo. of chains3Dimensions Overall length11200mmOverall width5350mmOverall height3900mmGround clearance1192mmLength of pontoon8500~10200mmWidth of pontoon1760mmHeight of pontoon1700mmOperating Scope Stick length3000mmA: Max. cutting height10980mmB: Max. dumping height8140mmC: Max. digging depth6940mmD: Max. reach10290mm
Why Choose Us
Swamp Buggy with Aluminum Track

Swamp Buggy with Aluminum Track
