• Model NO.：ZD160S-3
• Condition：New
• Color：Green
• Blade Type：Tilt Blade
• Working Mass：18100kg
• Blade Capacity：4.7m3
• Max. Lift Height of Dozer：1052mm
• Transport Package：Container
• Specification：18100kg
• Trademark：ZOOMLION
• Origin：Hunan
• HS Code：84291190
• Production Capacity：100units,Month

 ItemUnitZD160S-3Key    Technical ParameterBlade type-Tilt BladeWorking masskg18100Blade capacitym34.7Engine model-WD10G178E25Rated power/Slewing speedkW/rpm131Max. torqueN.m/rpm830/1100Min. fuel consumptiong/kW.h215Max. Drawbar pullKn152Ground pressurekPa31Gradeability°°30Traveling speed of forwardkm/h3.8/6.6/10.6Traveling speed of Reversekm/h4.9/8.5/13.6Basic    Technical ParameterHeight of cabmm3140Height of ROPSmm3244Ground contact lengthmm2935Height of blademm1039Track center distancemm2300Height of grousermm121Track shoe widthmm950Operating    RangeMax. lift height of dozermm1052Max. drop depthmm450Max. lift height of rippermm--Max. ripping depth of rippermm--Max. tiltmm730
