Single Drum Hydraulic Drive 14 Ton Weichai Engine Vibration Road Roller
Shanghai Vostosun Industrial Co., Ltd.- Type：Road Roller
- Working Method：Steel Wheel
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
- Compaction Depth：40cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：VSR728H
- Travel Speed：180
- Centrifugal Force：40KN
- Certification：CE, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Gradeability：35%
- Excitation Force Large / Small：147,163kn
- Quality of Work：28000kg
- Engine Model：Wp6g210
- Specification：7025*2358*3250
- Origin：China
- HS Code：9429401100
- Production Capacity：50sets,Month
Description
Shanghai VOSTOSUN Industrial Co., Ltd was founded in 2006, it is a subsidiary company of AVP GROUP, which has been focusing on centralized procurement and supply services for engineering, mining and Civil or Construction Project over the past decade.
Cooperating with excellent institutes in the domestic industries, domestic high-quality suppliers, international financial and insurance partners, we have integrated all high-quality resources and established a mature oversea regional service networks around the world, e.g, regional service centers in Russia, Kazakhstan and Australia, providing machinery, equipment and parts display, warehousing and after-sales services throughout the country. Our service covers more than 30 countries and regions including Eastern Europe, Central Asia, The Middle East, Africa, South America, Southeast Asia, and Australia,etc.
Since 2006, SHANGHAI VOSTOSUN, as the UN(United Nations) designated supplier for the procurement and supply of machinery & equipment for its aid projects in Asia and Africa, has provided lots of machineries, equipment and general contracting services for many national large-scale projects, such as:
·Kazakhstan Astana Capital Moving Project,
·Russia Voronezh Nuclear Power Station,
·Shanghai Pengxin Mining Congo (Gold) Copper Project,
·Equatorial Guinea National Highway Equipment General Contracting.
| MODEL | VSR728H | |
| Operating mass | Kg | 28000 |
| Static linear load | N/cm | 710 |
| Vibration amplitude | mm | 1.9/0.95 |
| Vibration frequency | Hz | 28/35 |
| Centrifugal force | kN | 480/380 |
| Travel speed | km/h | 11 |
| Gradeon ability | % | 35 |
| Turning radius | mm | 7500 |
| Overall dimension | mm | 7025*2358*3250 |
| Vibration round width | mm | 2130 |
| Wheelbase | mm | 3500 |
| Diesel model | WP6G210 | |
| Diesel power | KW | 154 |
