• Model NO.：ZL50GN
• Type：Small Loader
• Tire Specification：23.5-25
• Dumping Distance：1130mm
• Total Weight：17500kg
• Maximum Brakout Force：170kn
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：8165*3016*3485mm
• Origin：China
• HS Code：84295100
• Production Capacity：1000 Units, Month

Basic Info.

Model NO. ZL50GN Type Small Loader Tire Specification 23.5-25 Dumping Distance 1130mm Total Weight 17500kg Maximum Brakout Force 170kn Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 8165*3016*3485mm Origin China HS Code 84295100 Production Capacity 1000 Units/ Month

Product Description

5ton Small Wheel Loader ZL50GN with Cheap Price for Sale

1.Heavy load for the rocky condition, the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.

2.The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation.

3.The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.

4.The thickness of the front frame lug and baseboard is 70mm, and the thickness of the up and down articulated board is 30mm.
The machine is superior among the products of same kind in terms of the structural strength and carrying capacity.

5.Large distance between up and down articulated boards, and large maintenance space.
Resolve the load horizontally and vertically efficiently. Easier to access, the machine has more carrying capacity and larger opening space.

6.Each part passes the scientific analysis with professional stress analysis software to ensure that the reliability and carrying capacity of the structural parts could reach the design standard and meet the requirement of the tough condition.



Item	Parameters
Rated Load	5000kg
Rated Bucket Capacity	3.0m3
Total Weight	17500kg
Dumping Height(from ground to main blade plate)	3090mm
Dumping distance(from the front wheel to main blade plate)	1130mm
Maximum Brakout force	170kN
Max.tractive force	165kN
Lifting Time of swing arm	≤6.5S
Total cycling time	≤11S
Minimum turning radius(outer edge of bucket)	7300mm
Minimum turning radius(tire center)	6400mm
Articulated angle	35°
Gradeability	30°
Tire Specification	23.5-25
Overall dimensions of machine:L*W*H	8165*3016*3485mm
Engine model	WD10G220E23
Rated power/rotate speed	162/2000kW/r/min
Travel Speed                                                         Gear I(F/R)	0-11.5/0-16.5km/h
Travel Speed                                                         Gear II(F)	0~38km/h
