• Model NO.：HQ380
• Engine Power：<74kw
• Certification：CE, ISO9001: 2000, SGS
• Condition：New
• Color：Yellow
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Operating Weight：890kg
• Transport Package：by Container
• Specification：CE, GOST, ISO, SGS
• Trademark：HQ
• Origin：China
• HS Code：84295100
• Production Capacity：50000 Units , Year

Basic Info.

Model NO. HQ380 Engine Power <74kw Certification CE, ISO9001: 2000, SGS Condition New Color Yellow After-Sales Service Provided Engineers Available to Service Machinery Overseas Operating Weight 890kg Transport Package by Container Specification CE, GOST, ISO, SGS Trademark HQ Origin China HS Code 84295100 Production Capacity 50000 Units / Year

Product Description

1, Imported Brigges&Stratton Engine(from USA): 17.1Kw (23hp)
2, Italy hydraulic joystick
3. Solid tyre, (also can change to be engineering tyre, turf tyre, narrow tyre as your request)
Standard bucket
4, Haiqin quick hitch system makes fastening attachments quick and easy
5, Balance weight platform optional
6, Hydraulic joystick control optional
7, Compared with similar products, mini skid steer loader has a higher lifting height
8, Diesel engine and electric configuration optional

Item	HQ380
	with chevron engineering tyre
	metric
Max working height	2143mm
max pin height	1884mm
max dumping height	1488mm
max dumping distance	348mm
max dumping angle	30°
rollback of bucket on ground	25°
departure angle	11°
total height	1233mm
ground clearance	118mm
wheel base	636mm
overall length with bucket	1752mm
total width	1160mm
bucket width	980mm
total length with bucket	2206mm
turn radius forward turning	1307mm
engine
rated power	23HP
rotating speed	3600
noise	<=95
hydraulic system
pressure	17
working time
raise	4.27
dump	1.34
lower	3.31
operating load	200kg
t capacity	0.15m^3
max lifting force	375kg
travel speed	0-5.5km/h
operating weight	890kg
