• Model NO.：3Y152J
• Travel Speed：40cm,s
• Centrifugal Force：40KN
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Operating Weight：15t
• Color：Yellow
• Rated Power：60kw
• Engine：Yuchai Yc4d85z-T20 Engine
• Transport Package：Nude Packing
• Specification：ISO, CE
• Trademark：Oriemac
• Origin：Jiangsu, China
• Production Capacity：500,Month

Basic Info.

Model NO. 3Y152J Travel Speed 40cm/s Centrifugal Force 40KN Certification EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Operating Weight 15t Color Yellow Rated Power 60kw Engine Yuchai Yc4d85z-T20 Engine Transport Package Nude Packing Specification ISO, CE Trademark Oriemac Origin Jiangsu, China Production Capacity 500/Month

Product Description

Oriemac 15 ton three wheel static road roller 3Y152J
Operating weight: 12000 kg
Max. Operating weight: 15000kg
Yuchai YC4D85Z-T20 engine, 60kw

Model	Unit	3Y152J
Operation weight	kg	12000
Max. operation weight	kg	15000
Rear wheel max. static load	N/cm	1029
Travel speed	km/h
Speed I		3.08
Speed II		5.36
Speed III		12.01
Reverse speed I		3.12
Reverse speed II		5.43
Theoretical gradeability	%	20
Min. external turning radius	mm	6000
Min. ground clearance	mm	488
Compaction width	mm	2120
Roller overlap amount	mm	100
Engine model		YC4D85Z-T20
Type		Water cooling
Max. power @2200 r/min	kw	60
Overall length	mm	6224
Overall width	mm	2120
Overall height	mm	3297
Hydraulic oil tank capacity	L	70
Diesel oil tank capacity	L	130
Engine oil consumption	g.kW/h	22
