Front End Wheel Loader 3ton Lw300fn at a Low Price!
Evangel Industrial (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：LW300FN
- Type：Small Loader
- Transport Package：One Unit in One 40hq Container
- Specification：5930× 2078× 2850
- Trademark：EVANGEL
- Origin：China
Description
Main Specification | Unit | |
Bucket Capacity | m3 | 1.7 |
Rated Load | kg | 3000 |
Max. Digging Force | kn | 96 |
Max. Traveling Force | kn | 105 |
Operating Weight | kg | 10200 |
Model of Engine | TD226B/YuchaiYC6B125 | |
Rated Power | kw | 92 |
Rated Speed | r/min | 2200 |
Max. Torque | N.m | 500 |
Forward Travelling Speed | km/h | 6.6/13.8/30.1 |
Reverse Travelling Speed | km/h | 8.2/17/29 |
Max. Grade Ability | 27° | |
Steering Angle | ±38° | |
Mini Steering Radius | mm | 4885 |
Lifting Time | s | 5.1 |
Lowering Time | s | 3.0 |
Dumping Time | s | 1.1 |
Standard Tyre | 17.5-25-12PR | |
Dumping Clearance (45°) | mm | 2934 |
Dumping Reach (45°) | mm | 1043 |
Dimension(L*W*H) | mm | 6923*2305*3136 |
