Hot Sale Chinese Shantui 5 Ton Wheel Loader L58-B3 with Good Quality
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Warranty：1 Year
- Certification：ISO, RoHS
- Condition：New
- Rated Load：5 Ton
- Transmission：Hydraulic
Base Info
- Model NO.：L58-B3
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Small Loader
- Transport Package：Nude Package
- Specification：5 ton
- Trademark：Sinomada
- Origin：China
- HS Code：8429521200
- Production Capacity：50000pieces,Year
Description
Basic Info.
Model NO. L58-B3 Load and Unload Mode Front Discharge Walking Mode Wheeled Type Small Loader Transport Package Nude Package Specification 5 ton Trademark Sinomada Origin China HS Code 8429521200 Production Capacity 50000pieces/YearProduct Description
Hot Sale Chinese SHANTUI 5 Ton Wheel Loader L58-B3 with Good QualityPower SystemWeichai engine exclusively customized for Shantui conforms to the China-II non-road machinery emission regulation, featuring high intelligence and efficiency, high parts interchangeability, and low maintenance cost.
Driving/Riding Environment
The new generation cab with all-new design optimization and large door structure is mold formed to guarantee broader vision and more fashionable appearance.
The framework structure in four sides enlarges the interior space by >10% to ensure high safety, comfort, and reliability.
The extensively adjustable seat provides the driver with the most comfortable operation;
The locations of joysticks, pedals, and seat are reasonably arranged to achieve higher operating comfort.
| Parameter name | L58-B3 SG (Sand&stone version) | L58-B3 SG (Coal version) | L58-B3 MH (Ore version) |
| Performance parameters | |||
| Operating weight (Kg) | 17200 | 18000 | 17650 |
| Maximum dumping height (mm) | 3200 (Standard boom) 3450 (Extended boom) 3700 (Long Boom) | 3210 (Extended boom) 3420 (Long Boom) | 3215 (Standard boom) 3260 (Extended boom) |
| Dumping reach (mm) | 1230 (Standard boom) 1200 (Extended boom) 1270 (Long Boom) | 1395 (Extended boom) 1510 (Long Boom) | 1125 (Standard boom) 1310 (Extended boom) |
| Maximum breakout force (kN) | ≥185 | ≥185 | ≥185 |
| Total cycle time (s) | 10.5 | 10.5 | 10.5 |
| Engine | |||
| Engine model | WP10 | WP10 | WP10 |
| Rated power/rated speed (kW/rpm) | 162/2000 | 162/2000 | 162/2000 |
| Overall dimensions | |||
| Overall dimensions of machine (mm) | 8100*3030*3540 | 8460*3050*3540 | 8160*3075*3540 |
| Driving performance | |||
| Forward speed (km/h) | F1:0-13, F2:0-40 | F1:0-13, F2:0-40 | F1:0-13, F2:0-40 |
| Reversing speed (km/h) | R:0-15 | R:0-15 | R:0-15 |
| Chassis System | |||
| Wheelbase (mm) | 3300 | 3300 | 3300 |
| Tank capacity | |||
| Fuel tank (L) | 230 | 230 | 230 |
