Liugong New Condition 15 Ton Crawler Excavator Clg915dii
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Crawler Excavator
- Usage：Marine Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：CLG915DII
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：New
- Model：Clg915dii
- Operating Weight：13900 Kg
- Engine：USA Imported Diesel Engine
- Gross Power：86 Kw
- Peak Torque：447 N.M
- Maximum Dig Height：8765 mm
- Maximum Dig Depth：5470 mm
- Emission Regulation：Tire 2
- Warranty：12 Months
- Rated Speed：3.2-5.4km,H
- Transport Package：Nude Package
- Specification：ISO, CE, GOST
- Trademark：Liugong
- Origin：China(Mainland), Guangxi
- Production Capacity：1500 Units, Year
Description
Basic Info.
Model NO. CLG915DII Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Model Clg915dii Operating Weight 13900 Kg Engine USA Imported Diesel Engine Gross Power 86 Kw Peak Torque 447 N.M Maximum Dig Height 8765 mm Maximum Dig Depth 5470 mm Emission Regulation Tire 2 Warranty 12 Months Rated Speed 3.2-5.4km/H Transport Package Nude Package Specification ISO, CE, GOST Trademark Liugong Origin China(Mainland), Guangxi Production Capacity 1500 Units/ YearProduct Description
Liugong New Condition 15 ton Crawler Excavator CLG915DII
Advantages:
1.A water proof ring prevents rainwater from entering the swing bearing
2.Vertical installation of the main valve makes it quicker and more convenient to disassemble hoses
3.The improved pipeline layout also leads to less problems and easier maintenance.
4.Integrated solenoid valve with pilot valve block placed at the front of the main control valve. This design increases space with in the machine, opening the front cover allows for convenient maintenance of pilot valve block.
Specifications:
| Operating Weight | 13,900 kg |
| Bucket Capacity | 0.36-0.73 m³ |
| Engine | B3.9 |
| Gross Power | 86 kW (115.3 hp) @ 2,200 rpm |
| Net Power | 80.2 kW (107.5 hp) @ 2,200 rpm |
| Peak Torque | 447 N·m @ 1,500 rpm |
| Travel Speed | High:5.4 km/h Low: 3.2 km/h |
| Drawbar Pull | 124.3 kN |
| Swing Speed | 12.9 rpm |
| Arm Breakout Force, max, ISO | 60.4 kN |
| Bucket Breakout Force, max, ISO | 83.5kN |
| Maximum Dig Depth | 5,470 mm |
| Reach at Ground Level | 8,215 mm |
| Depth of 8' Level Bottom | 5,255 mm |
| Maximum Dig Height | 8,765 mm |
| Dump Height | 6,305 mm |
| Maximum Dig Depth of Vertical Wall | 4,810 mm |
| Overall Lenth | 7,780 mm |
| Overall Width | 2,590 mm |
| Overall Height | 2,860 mm |
