OVERALL DATA |
Bucket Capacity | 2.7m³ |
Rated Payload | 5000kg |
Operating Weight | 15800±300kg |
Traction Force | 155±3kN |
Breakout Force | 155±3kN |
L×W×H | 7760×3000×3380mm |
ENGINE&ELECTRICAL SYSTEM |
Maker/Model | WEICHAI/WD10G220E21 |
Emission Standard | EPA (Tier 2)/National 2 |
Engine Type | 4 Stroke,Turbocharged,Water-cooled,Direct Injection,Diesel Engine |
Rated Power | 162kW(220hp)/2200rpm |
Maximum Torque | 860N·m/1400-1600rpm |
Bore x Stroke (mm) | 126×130 |
No. of Cylinders/Displacement | 6/9.726L |
Compression Ratio | 17 |
Air Cleaner | Three Stage Air Cleaner with Cyclone Pre-cleaner |
Alternator | 55Amp |
Battery | 2-24V/120Ah |
Starting Motor | 24V/7.5kW |
Heating Capacity (W) | 5000W |
Cooling Capacity (W) | 4700W |
DRIVE TRAIN |
Transmission Type | Planetary Powershift Transmission |
Shift Type | Mechanical Powershift Control |
Pressure of Transmission | 1.2-1.5MPa |
Torque Converter Type | Single-stage,Duo-turbine,4-element |
Torque Ratio | 4 |
Axles | Rigid Front Axle&Oscillating Rear Axle |
Rear Axle Oscillation (°) | ±10° |
Differential | Conventional |
Main Reducer | Spiral Bevel,1-stage Reduction |
Final Reducer | Planetary Reduction |
Tire | 23.5-25 L-3 16PR TT |
Travel Speeds | km/h | 1st | 2nd |
Forward | 11.5 | 36 |
Reverse | 16 | |
BRAKE SYSTEM |
Service Brake | Single Circuit Caliper,Dry Brake |
Setting Pressure | 0.70-0.78MPa |
Parking Brake | Flexible Shaft Controlled Caliper Brake |
Emergency Brake | Flexible Shaft Controlled Caliper Brake |
STEERING SYSTEM |
Type | Hydraulic Load Sensing System |
Pump | Gear Pump,152L/min·2200rpm |
System Pressure | 15MPa |
Cylinder | Type | Double Acting |
Bore x Stroke | 2-90×324mm |
Steering Angle | ±35° |
HYDRAULIC SYSTEM |
Type | Single-lever(Joystick) Control | | |
Pump | Gear Pump,190L/min·2200rpm | | |
Control Valve | 2 Spool (Bucket&Boom) | | |
System Pressure | 16MPa | | |
Cylinder | Lift Cylinder | 2-160×836mm |
No.-Bore x stroke | Tilt Cylinder | 1-180×559mm |
Joystick Control Pressure | 2.5MPa |
Cycle Time (Sec) | 11.5 |
SERVICE REFILL CAPACITY |
Fuel Tank (L) | 280L |
Hydraulic Tank (L) | 245/250(3rd Spool for Auxiliary Function)L |
Crankshaft (L) | 20L |
Transmission (L) | 46L |
Front Axle/Rear Axle (L) | 28L/28L |
