10 Ton Small Pneumatic Asphalt Road Roller with Smooth Rubber Tyre for Sale
Sinoway Industrial (Shanghai) Co., Ltd.- Warranty：One Year
- Type：Road Roller
Base Info
- Model NO.：SWP1016H
- Working Method：Wheeled
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Light Grind
- Compaction Depth：30cm
- Engine Type：Diesel Engine
- Travel Speed：40cm,s
- Centrifugal Force：None
- Certification：CE, ISO 9001:2008, ISO14001
- Condition：New
- Tire Number：F4+R5
- Tire Size：11.00-20
- Compaction Width：2286 mm
- Fuel Tank：220 L
- Engine Power：100 HP
- Engine：Cummins
- Transmission：Hydraulic
- A/C：Standard
- Weight：10-16 Ton
- Transport Package：Nude
- Specification：ISO
- Trademark：SINOWAY
- Origin：China
- HS Code：84314990
- Production Capacity：200 Unit Per Year
- Package size per unit product：498.00cm * 225.00cm * 330.00cm
- Gross weight per unit product：10000.000kg
Description
EngineModel Cummins 4BT3.9 Type Four-cylinder,water-cooled turbocharged,mechanical injection Rated power 75kw Rated speed 2200rpm Transmission Type Mechanical drive (Gear box) Grade ability 20% Gear shifts(Forward/Reverse) F3/R2 Travelling speed (km/h) Forward/Reverse I 6.0/4.5 Forward/Reverse II 14.0/10.9 Forward III 16.0 Axle and Tyre Type of main reducer Spiral bevel gear Gear ratio 1:6.17 Final reducer Chain driven Chain gear ratio 1:2.17 Single tire load (F/R) 1778kg Tyre number (F+R) 4+5 Tyre size 11.00-20 Main Technical Specification Max. operating weight 16000Kg Min. operating weight 10000kg Average ground pressure 0.15 - 0.3MPa Tyre pressure 0.2 - 0.8MPa Compacting width 2286mm Vertical oscillation ± 100mm Steering System Type Hydraulic steering Working pressure 13MPa Steering cylinder 90 x 50 x 260mm Min. steering radius 7500mm Braking System Service brake Air-over-hydraulic disc brake Parking brake Hand operated drum brake Service Capacities Hydraulic tank 67L Gear box 10L Fuel tank 220L Engine crank case 16L Dimensions Overall length 4980mm Overall width 2286mm Overall height 3220mm Wheelbase 3700mm Ground clearance 300mm
