China Sem 190HP 919 Motor Grader Good Price Sem919
Jinan Quan Yu Import and Export Co., Ltd.- Certification：ISO, CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic
- Walking Mode：Wheeled
- Type：Medium-sized Grader
Base Info
- Model NO.：SEM
- Transport Package：Nude
- Specification：8.703*2.630*3.360 mm
- Trademark：sem
- Origin：China
Description
Motor Grader
SEM919
Operating weight
15070 kg
Overall dimension (L*W*H)
8703*2630*3360 mm
Blade dimension (L*W*H)
3974*25*607 mm
Max. Lifting height
475 mm
Max. cutting depth
715 mm
Max. Drawbar
78 kN
Wheel base
6140 mm
Frame articulation angle
25 o
Engine
SDEC SC9DK190.1G3
Rated power
140 kW
Transmission type
Hangchi 6WG180
Travel speed (Forward / Reverse)
40 / 25 km/h
Rear Axle/Tandem
SEM ST22
Service brake
Outboard disc with brake caliper, Air to oil Control
Oscillation (Front up/Rear up)
15 / 25 o
Max. Oscillation Angle
+/- 16 o
Steering Angle (Left/Right)
47.5 o
Max. Lean Angle of Front Wheels
18 o
Hydraulic system
Load sensing, PPPC
Fuel tank capacity
320 L
Hydraulic oil tank capacity
55 L
Our company
Jinan Quanyu Import and Export Co., Ltd. is one of the main exporters of Chinese trucks which is authorized by Ministry of Commerce, and our company belong to SINOTRUK sales department and we have specialized in sinotruk trucks and spare parts for many years.The famous brand of sinotruk are HOWO series,HOWO A7 series,HOHAN series.We can supply tractor truck,dump truck,cargo truck,concrete mixer truck,fire tanker truck,water truck,fuel tank truck,bulk cement truck,sewage suction truck and also different types of semi trailers.
SINOTRUK is located in Jinan city and was founed in 1956.It once manufactured china's first heavy duty truck.In 1960,sinotruk introduced the steyr technology using on engine and axle from Austria.Later,sinotruk established cooperation with German man group and wobaco company.Today,sinotruk has developed into china's largest heavy duty truck manufacturing base and made significant contributions to the development of china's heavy duty truck industry and national economic growth.
We have not only the certificate and license of truck export and also strict quality management, fast and convenient channel of goods delivery, strict examination in quality and quantity of products, professional packing, professional and reliable loading goods, on-time delivery and competitive prices. If you want to buy these products, please contact us.
We sincerely hope to cooperate with you to expand market in your country!
Certificates
Prouducts Quality
1.Quality is life and our company is confident in the superior quality of our products and is the most effective salesman.
2. Our company has advanced production management and research and development technology, and continues to carry out technical innovation.
3. Our company introduced automatic integrated molding production equipment, which greatly reduced production process and ensured product quality stability.
4. Our company has its own set of testing methods and standards.
