• Model NO.：FL966H
• Type：Medium-sized Loader
• Operating Mass(Kg)：20600
• Bucket Capacity：4
• Rated Load(Kg)：6500
• Traction(Kn)：175
• Digging Force(Kn)：185
• Unloading Height(mm)：3150
• Unloading Distance(mm)：1310
• Wheelbase(mm)：3400
• Model：Weichai Wd10g240e21
• Rated Power(Kw)：178
• Transport Package：Nude
• Specification：FL966H
• Trademark：LOVOL
• Production Capacity：1000 Units Per Month

Operating mass(kg)20600Bucket capacity4Rated load(kg)6500Traction(kN)175Digging force(kN)185Gradeability29Unloading height(mm)3150Unloading distance(mm)1310Min. ground diatance(mm)445Wheel tread(mm)2250Wheelbase(mm)3400Bucket outer turning radius(mm)7130Outline distance(mm)8530*3050*3400EngineModelWeichai WD10G240E21Max. torque(N·m)980Rated power(kW)178Rated rotational speed(rpm)2200Running systemGearbox shiftFront:4 gears Rear:3 gearsMax. speed38.0Type23.5-25Ply rating20Steering angle38OtherOperating modelPilot controlSum of three items(s)11.0Fuel tank(L)350Hydraulic oil tank(L)151





Product specifications

Supporting EquipmentStandard bucket, stone bucket, quickchange bucket, quick change bottom fork, wooden fork, grass fork, fork; cold start device can be optionally equipped to deal with the cold circumstance
