Sunward Swe210e New Technology Mini Buckets Excavator Wheeled for Sale
Sunward Intelligent Equipment Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：0.6mmm
Base Info
- Model NO.：SWE210E
- Size：7815X2600X2825 mm
- Certification：ISO9001
- Condition：New
- Warranty：2 Years
- Rated Speed：5.4,Km,H
- Hydraulictank：150L
- Maximum Digging Depth：5640mm
- Hydraulic Pump Brand：Kyb
- Operatingweight：14.8t
- Operating Weight：20 Ton
- Moving Type：Crawler Excavator
- Hydraulic Cylinder Brand：Kyb
- Maxdiggingheight：8630mm
- Power：84kw,2200rpm
- Maximum Digging Height：8630mm
- Wheelbase：3000mm
- Max Digging Radius：8355
- Local Service Location：Indonesia
- Specification：20 Ton
- Trademark：SUNWARD
- Origin：Hunan, China
- Production Capacity：100000 Set,Sets Per Year
Description
Size(L×W×H)9590×2800×3045 mm A)Wheel-base 3465mm B)Crawler length 4260mm C)Ground clearance of platform 1060mm D)Tail slewing radius of platform 2750mm E)Width of upper body 2710mm F)Gauge 2200mm G)Chassis width 2800mm H)Track width 600mm I)Chassis ground clearance 470mm J)Cab roof height 2965mm K)Transport boom height 3045mm L)Transport length 9590mm a)Max.digging height 9740mm b)Max.dumping height 6980mm c)Max.digging depth 6690mm d)Max. vertical digging depth 6040mm e)Max.digging radius 9950mm f)Max.digging reach at ground level 9785mm Operating weight(steel track) 21.3t Standard bucket capacity 0.95m3 Bucket digging force 154kN Bucket rod digging force 110kN Travel speed(Max./Min.) 4.9/3.1 km/h Ground pressure 43.2kPa Swing speed 11.8rpm Engine Brand ISUZU Model 6BGITRP-03 Type 6-cylinder, 4-stroke, water-cooled Power 110kW/2100rpm Displacement 6.494L Fuel tank 370L Hydraulic tank 250L
Outline dimension
Operating range
Performance parameters
Oil tank capacity
