21.5 Ton Large Digger Bucket Track Crawler Excavator Sy215c
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Online Support
- Warranty：1year
- Type：Crawler Excavator
- Usage：Mining Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SY215C
- Drive Type：Internal Combustion Drive
- Bucket Capacity：3.3cbm
- Size：Small-Scale
- Certification：CE
- Condition：New
- Engine Power：114kw
- Transport Package：4510*1450*2395mm
- Specification：20975kg
- Trademark：sinomada
- Origin：China
- Production Capacity：50000PCS,Year
Description
Main specification
Unit
SY215C
Operating weight
kg
20975
Standard bucket capacity
m³
0.93
Rated power
kw/rpm
114/2050
Length
mm
9395
Width
mm
2980
Height
mm
2955
Headpiece width
mm
2710
Mouldboard height
mm
2990
Standard mouldboard width
mm
600
Gauge
mm
2380
Minimum ground clearance
mm
440
Tail gyroradius
mm
2750
Tread
mm
3445
Track length
mm
4250
Maximum digging height
mm
9305
Discharge height
mm
6475
Max digging depth
mm
6630
Max vertical arm digging depth
mm
5980
Maximum digging distance
mm
9885
Least radius gyration
mm
3630
Least radius gyration height
mm
7570
Speed of travel(high/low)
km/h
5.5/3.2
Rotating speed
rpm
11
Gradeability
%/°
70/35
Ground clearance
kpa
45
Bucket digging ability
kN
138
Pole digging capacity
kN
100
