• Model NO.：SD52-5E
• Condition：New
• Color：Yellow
• Transport Package：by Sea-
• Trademark：Shantui
• Origin：China
• HS Code：84291190
• Production Capacity：500,Month

PRODUCTSD52-5E(STANDARD)PERFORMANCE PARAMETERSOperatiing   Weight (kg)70630Rated horsepower (kw/hp)450/604(1800)Minimum turning radius (mm)3864/6786Ground pressure (kpa)151ENGINEModelCHONGQING   CUMS QSK19EmissionEU   A/CHINATypeIn-line,water   cooled,4-cycles,turbocharged,aftercooled,electric controlNo.of cylinders×Bore×stroke (mm×mm)6×159mm×159mmPiston displacement (L)19Horsepower/rpm (kw/rpm)450/1800Maximum torque (N.m/r/min)3019/1300DIMENSIONSLength   (mm)10390Width (mm)4690Height (mm)4370TRAVELING PERFORMANCEForward/Reverse   (km/h)0~11.8/0~15.8Gradeability (deg)30Clearance (mm)610TRANSMISSIONTorque   convertorConsists   of a water-cooled,Gear boxPlanetary   gear, multi-disc clutch, power shift, forced lubricationMain driveSpiral   bevel gear, splash lubrication, single-stage speed reductionClutchWet,   multi-disc, spring loaded, hydraulically separated, hydraulic controlBrakeWet,multi-disc,spring   loaded,hydraulically separatedFinal driverPrimary   spur gear plus primary planetary gear reducerSteering pump 2 Gear pump,pump1 flow 112mL/r,pump2 flow   160mL/rUNDERCARRIAGESuspensionOscillating   equalizer bar and pivot shaftTrack gauge (mm)2500Shoe width (mm)610(710/810   optional)Track length on ground (mm)3840Number of shoes (each side)40Pitch (mm)280Carrier rollers (each side)2Track rollers (each side)7WORKING HYDRAULIC SYSTEMWorking   pumpGear   pumpScavenging pumpGear   pumpPump of cooling systemvariable   displacement piston pump, standard flow 140mL/rValveMulti-way   valveBore of blade lift cylinder (mm)φ150Bore of blade tilt cylinder (mm)φ225Bore of ripper lift cylinder (mm)φ225Bore of ripper tilt cylinder (mm)φ200TANK CAPACITYFuel   tank capacity (L)1140Working hydraulic tank capacity (L)246Transmission hydraulic tank capacity (L)275WORKING EQUIPMENTBlade   width (mm)4690Blade height (mm)2250Blade capacity (m³)18.5Maximum lifting height of ripper (mm)1105Maximum digging depth of ripper (mm)1435
