Changlin 1.2m3 Bucket Mini and Small Backhoe Loader Wz30-25
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：ISO, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Power
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：WZ30-25
- Type：Small Loader
- Tire Specification：23.5-25
- Dumping Distance：1130mm
- Total Weight：17500kg
- Maximum Brakout Force：170kn
- Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification：6970*3330*2245 mm
- Trademark：CHANGLIN
- Origin：China
- HS Code：84295100
- Production Capacity：1000 Units, Month
Description
Overall Dimension
1
Length(with bucket on ground)
7077(mm)
2
Width
2350(mm)
3
Load Bucket width
2313(mm)
4
Height(To the top of the cab)
2720 (mm)
5
Height(To the top of the digging pole)
3424 (mm)
6
Wheelbase
2155.5(mm)
7
Back wheel Tread
1557(mm)
8
Fore wheel Tread
1714(mm)
9
Min. ground clearance
355(mm) for 2WD 275(mm) for 4WD
Main Loading Technical Specification
1
Rated load
1700(Kg)
2
Operating weight
7000KG
Max lifting capability
>2500KG
3
Rated load bucket capacity
1.0(m3)
4
Max. load breakout force
>40kN
5
Max. dump clearance
2611(mm)
6
Dump reach
726(mm)
7
Dump angle at any position
≥43.50
8
Min. turning radius
