Gr215 215HP China Motor Grader with Hydraulic Pump
Shanghai Super-Above Industry Holdings Co., Ltd.- Condition：New
- Application：Railway, Mine, Farmland, Highway
Base Info
- Model NO.：GR215 motor grader
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Large Grader
- After-Sales Service Provided：Overseas Service
- Drive Type：Rear-Axle Drive
- Engine Model：6CTA8.3-C215
- Rated Power/Speed：160kw,2200rpm
- Dimension：8970X2625X3420mm
- Operating Weight：16500kg
- Max. Gradeability：20%
- Tire Inflation Pressure：260kpa
- Working Hydraulic Pressure：16MPa
- Transmission Pressure：1.3~1.8MPa
- Tractive Force：87kn
- Maximum Lift Above Ground：450mm
- Maximum Depth of Cutting：500mm
- Moldboard Width X Height：4270X610mm
- Blade Cutting Angle：28-70degree
- Transport Package：Naked in Container
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8429209000
- Production Capacity：5000PCS,Year
Description
Oil filling amountCoolant 50L Fuel tank 280L Engine 24L Transmission 38L Balancing box 46L Drive axle 28L Hydraulic oil 110L
