Cheap Price Chinese Medium Digger Crawler Excavator Se470LC New Bagger for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Any
- Warranty：1 Year Warranty
- Type：Crawler Excavator
- Usage：Special Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE470LC
- Drive Type：Electric Drive
- Bucket Capacity：0.55~2.5(2.2)M³
- Size：Medium-Sized
- Certification：CE
- Condition：New
- Transport Package：Cartons
- Trademark：Sinomada
- Origin：China
- HS Code：8429521200
- Production Capacity：500000
Description
Basic Info.
Model NO. SE470LC Drive Type Electric Drive Bucket Capacity 0.55~2.5(2.2)M³ Size Medium-Sized Certification CE Condition New Transport Package Cartons Trademark Sinomada Origin China HS Code 8429521200 Production Capacity 500000Product Description
Cheap Price Chinese Medium Digger Crawler Excavator SE470LC New Bagger For Sale
Enhanced working deviceThe design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
| Comparative item | SE470LC (Standard version) |
| Overall dimensions | |
| Overall length (mm) | 12110 |
| Ground length (During transport) (mm) | 6660 |
| Overall height (To the top of boom) (mm) | 3745 |
| Overall width (mm) | 3360 |
| Overall height (To top of cab) (mm) | 3330 |
| Ground clearance of counterweight (mm) | 1395 |
| Minimum ground clearance (mm) | 590 |
| Tail turning radius (mm) | 3720 |
| Track length (mm) | 5315 |
| Track gauge (mm) | 2760 |
| Track width (mm) | 3360 |
| Standard track shoe width (mm) | 600 |
| Turntable width (mm) | 3190 |
| Distance from slewing center to tail (mm) | 3675 |
| Working range | |
| Maximum digging height (mm) | 10785 |
| Maximum dumping height (mm) | 7600 |
| Maximum digging depth (mm) | 7815 |
| Maximum vertical digging depth (mm) | 6295 |
| Maximum digging distance (mm) | 12040 |
| Maximum digging distance at ground level (mm) | 11830 |
| Working device minimum turning radius (mm) | 4840 |
| Maximum lifting height of bulldozer blade (mm) | - |
| Maximum digging depth of bulldozer blade (mm) | - |
| Engine | |
| Model | QSM11(China III) |
| Type | Inline 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
| Displacement (L) | 10.8 |
| Rated power (kW/rpm) | 250/2000 |
| Hydraulic system | |
| Type of hydraulic pump | Variable displacement duplex plunger pump |
| Rated working flow (L/min) | 360×2+27 |
| Bucket | |
| Bucket capacity (m³) | 0.55~2.5(2.2) |
| Swing system | |
| Maximum swing speed (r/min) | 10 |
| Brake type | Mechanically applied and pressure released |
| Digging force | |
| Bucket arm digging force (KN) | 242 |
| Bucket digging force (KN) | 288.5 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 46800 |
| Ground pressure (kPa) | 81.9 |
| Traveling system | |
| Traveling motor | Axial variable displacement plunger motor |
| Traveling speed (km/h) | 3.3/5.6 |
| Traction force (KN) | 364 |
| Gradeability | 70%(35°) |
| Tank capacity | |
| Fuel tank capacity (L) | 620 |
| Cooling system (L) | 34 |
| Engine oil capacity (L) | 35 |
| Hydraulic oil tank/system capacity (L) | 366/460 |
