Hyundai 22ton Crawler Excavator 225lvs Medium Excavators Tier 3
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Free Spare Parts
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：Marine Excavator
- Bucket：Backhoe
- Transmission：Mechanical Transmission
Base Info
- Model NO.：225LVS
- Drive Type：Internal Combustion Drive
- Bucket Capacity：1.0~1.5m³
- Size：Medium-Sized
- Certification：CE
- Condition：New
- Rated Power (Kw/Rpm)：153(113) , 1900
- Displacement (L)：6.7
- Maximum Torque (N.M/Rpm)：63 , 1500
- Bore Diameter * Stroke (mm)：107×124 mm
- Cooling Mode：Water Cooling
- Fuel Tank (L)：400
- Hydraulic Tank (L)：160
- Hydraulic System (L)：275
- Transport Package：Nude
- Specification：9550*2990*3080mm
- Trademark：HYUNDAI
- Origin：China
- HS Code：8454543131
- Production Capacity：10units,Month
Description
Basic Info.
Model NO. 225LVS Drive Type Internal Combustion Drive Bucket Capacity 1.0~1.5m³ Size Medium-Sized Certification CE Condition New Rated Power (Kw/Rpm) 153(113) / 1900 Displacement (L) 6.7 Maximum Torque (N.M/Rpm) 63 / 1500 Bore Diameter * Stroke (mm) 107×124 mm Cooling Mode Water Cooling Fuel Tank (L) 400 Hydraulic Tank (L) 160 Hydraulic System (L) 275 Transport Package Nude Specification 9550*2990*3080mm Trademark HYUNDAI Origin China HS Code 8454543131 Production Capacity 10units/MonthProduct Description
HYUNDAI 22ton crawler excavator 225LVS medium excavators Tier 3
. Focused on special automobiles' design and production for nearly 10 years.
. Obtained the ISO9001 international quality management system certification.
. Achieved foreign trade qualification granted by Chinese government.
. Manufacturer direct sale,quality guaranteed, low price.
. Europe Emission Standard 2/3/4/5.
. Except standard products, also customize products according to your requirements.
Parameters:
Bucket: backhoe
Working weight of the whole machine (kg): 19500
Bucket capacity (M:): 1.05m3
Engine: Cummins QSB6.7
Rated power (kw/rpm):153(113) / 1900
Maximum torque (N.m/rpm): 63 / 1500
Displacement (L): 6.7
Bore diameter * stroke (mm):107×124 mm
Cooling mode: water cooling
Working form: 6 cylinder 4 stroke water-cooled direct injection engine
Walking hydraulic circuit (Mpa): 350
Rotary hydraulic circuit (Mpa): 350
Fuel tank (L): 400
Hydraulic tank (L): 160
Hydraulic system (L): 275
Coolant (L): 24
Length (mm): 9550
Width (mm): 2990
Height (mm): 3080
Cab full height (mm): 2920
Counterweight ground clearance (mm): 1060
Maximum digging radius (mm): 9980
Maximum digging depth (mm): 6730
Maximum excavation height (mm): 9600
