• Model NO.：LG818D
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Maximum Traction Force：53kn
• Transport Package：7245X2482X3050 mm
• Specification：6200KG
• Trademark：SINOMADA
• Origin：China
• Production Capacity：50000PCS,Year

 Way of walkingWheeledLoading and unloading methodsFront unloadingTypes ofSmallPerformance parameter Maximum traction force (KN)53Gradeability(%)70Working weight of the whole machine (kg)5600Standard bucket capacity (m³)1.05Rated load (kg)1800Maximum digging force (kN)52Unloading height (mm)2700Lifting time (s)4.9engine Engine typeIn-line, water-cooled, four-stroke, direct injectionRated power KW (HP)60Rated speed (rpm)2400Maximum torque (N·m)275Total displacement of engine (L)4.4Fuel consumption rate (g/kw·h)242  1. High-quality, industry-leading manufacturing equipment and technological processes are the most reliable guarantee of quality;
2. Optimized design, and the main components have strong versatility;
3. The selection of hydraulic gearbox and torque converter is more reliable for power transmission and more flexible;
4. Large wheelbase, reasonable bridge load distribution, high tractive force and breakout force, good overall machine form and operation stability;
5. The layout of the oil and hydraulic oil tanks is reasonable, and the hood is opened on the side, which is convenient for maintenance;
6. Using low-pressure wide-base off-road tires, the rear axle can swing up and down around the center, so it has good off-road performance and passing performance, and is suitable for driving and working on rough roads;
7. The pin bushing adopts a sealing structure, which is dust-proof and anti-fouling, and improves the service life;
8. Adopt articulated structure, small turning radius, flexible steering, use and narrow space operation;
9. The single-pump diversion system is adopted, which saves energy and reduces consumption, and has high operating efficiency;
10. The frame structure adopts finite element analysis technology, and the working stress part adopts the structure of enhanced rigidity and strength;
11. The link mechanism of the working device is optimized, the working time of the working device is shortened, and the operation efficiency of the whole machine is improved;
12. Equipped with high wear-resistant blade to improve the service life of the bucket
