• Model NO.：JC70
• Operating Load(Kg)：1000
• Dumping Angle at Maximum Height(°)：40
• Dumping Height(mm)：2250
• Dumping Reach(mm)：750
• Wheelbase(mm)：1020
• Bucket Width(mm)：1880
• Rated Power (Kw)：55
• Max. Speed (Km/H)：12
• Transport Package：Nude,Container
• Specification：CE ISO9001: 2000
• Trademark：SINOHENG
• Origin：China
• Production Capacity：500PCS,Month

Model
Main technical parameterJC70AOverall operating height(mm)3690BHeight to bucket hinge pin(mm)2920CHeight to top of cab(mm)2160DHeight to bottom of level bucket(mm)2753EOverall length without bucket(mm)2780FOverall length with bucket(mm)3540GDumping angle at maximum height(°)40HDumping height(mm)2250IDumping reach(mm)750JRollback of bucket on ground(°)30KRollback of bucket at full height(°)104LWheelbase(mm)1020MGround clearance(mm)205NAngle of departure(°)20OFront turning radius without bucket(mm)1216PFront turning radius(mm)2068QRear turning radius(mm)1820RRear axle to bumper(mm)1082STread width, centerline to centerline(mm) 1500TWidth(mm)1880UBucket width(mm)1880

Model	JC70
Engine model	498
Bore x stroke(mm)	98×105
Rated power (Kw)	55
Rotating speed(rpm)	2450
Number of cylinders	4
Max. torque (N.m)	245
Displacement  (L)	3.168
Max. Speed  (km/h)	12
Tire(track)  modei	12-16.5
Operating load(kg)	1000
Lifting	Arc lifting
Bucket capacity(m3)	0.5
Rated flux(L/min)	75
High Flow Flux(L/min)
Fuel tank capacity(L)	75
Self weight bucket(kg)	3500
