Shantui Hot Model 21ton Crawler Excavator with 0.9m3 Bucket Capacity
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE215
- Drive Type：Internal Combustion Drive
- Bucket Capacity：>1.5m³
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：New
- Bucket Capacity (M³)：0.9
- Transport Package：Nude
- Specification：21900kg
- Trademark：shantui
- Origin：China
- HS Code：8429510000
- Production Capacity：500,Month
Description
Product Description Comparative item SE215 (Standard version) Overall dimensions Overall length (mm) 9625 Ground length (During transport) (mm) 4915 Overall height (To the top of boom) (mm) 3075 Overall width (mm) 2800 Overall height (To top of cab) (mm) 3055 Ground clearance of counterweight (mm) 1075 Minimum ground clearance (mm) 470 Tail turning radius (mm) 2925 Track length (mm) 4140 Track gauge (mm) 2200 Track width (mm) 2800 Standard track shoe width (mm) 600 Turntable width (mm) 2725 Distance from slewing center to tail (mm) 2920 Working range Maximum digging height (mm) 10095 Maximum dumping height (mm) 7190 Maximum digging depth (mm) 6490 Maximum vertical digging depth (mm) 5915 Maximum digging distance (mm) 9860 Maximum digging distance at ground level (mm) 9675 Working device minimum turning radius (mm) 2970 Maximum lifting height of bulldozer blade (mm) - Maximum digging depth of bulldozer blade (mm) - Engine Model Famous Brand QSB7 (China-III) Type 6-cylinder, high pressure common rail, and water-cooled and turbocharged Displacement (L) 6.7 Rated power (kW/rpm) 124/2050 Hydraulic system Type of hydraulic pump Variable displacement duplex plunger pump Rated working flow (L/min) 2x213 Bucket Bucket capacity (m³) 0.9 Swing system Maximum swing speed (r/min) 11 Brake type Mechanically applied and pressure released Digging force Bucket arm digging force (KN) 135/146 Bucket digging force (KN) 99/107 Operating weight and ground pressure Operating weight (kg) 20800 Ground pressure (kPa) 47.5 Traveling system Traveling motor Axial variable displacement plunger motor Traveling speed (km/h) 3.15/5.15 Traction force (KN) 214 Gradeability 70%(35°) Tank capacity Fuel tank capacity (L) 330 Cooling system (L) 28 Engine oil capacity (L) 22 Hydraulic oil tank/system capacity (L) 270/400
