9.5m Width Road Paver Laying Machine Small Asphalt Pavers Price
Acntruck Automobile Sales (Shanghai) Co., Ltd.- After-sales Service：Field Installation, Commissioning and Training
- Warranty：1 Year
- Type：Paver
- Object：Asphalt Concrete Pavement
- Moving Type：Mobile
- Mixing Method：Intermittent Compulsory
Base Info
- Model NO.：BF800
- Automatic Grade：Semi-Automatic
- Product Capacity：40～400t,h
- Certification：ISO9001: 2000, CE
- Condition：New
- Speed：0-4.5km,H
- Engine Model：Tcd 2012 L06
- Emission Standard：Tier 3
- Cooling：Water Cooling
- Number of Cylinder：6
- Rated Speed：2000rpm
- Weight：21000kg
- Maximum Paving Thickness：300mm
- Hopper Capacity：7.2t
- Walking Type：Crawler Type
- Engine Power：135kw
- Fuel Tank Capacity：315L
- Conveyor Belt：2
- Transport Package：Nude Package, Suitable for Shipment
- Specification：6800*2550*3055mm
- Trademark：Acntruck
- Origin：China
- HS Code：8429510000
- Production Capacity：100 Pieces,Month
Description
Basic Info.
Model NO. BF800 Automatic Grade Semi-Automatic Product Capacity 40～400t/h Certification ISO9001: 2000, CE Condition New Speed 0-4.5km/H Engine Model Tcd 2012 L06 Emission Standard Tier 3 Cooling Water Cooling Number of Cylinder 6 Rated Speed 2000rpm Weight 21000kg Maximum Paving Thickness 300mm Hopper Capacity 7.2t Walking Type Crawler Type Engine Power 135kw Fuel Tank Capacity 315L Conveyor Belt 2 Transport Package Nude Package, Suitable for Shipment Specification 6800*2550*3055mm Trademark Acntruck Origin China HS Code 8429510000 Production Capacity 100 Pieces/MonthProduct Description
9.5M Width Road Paver Laying Machine Small Asphalt Pavers PriceConfiguration:
1. The screed is equipped with a tamper and vibration, and its vibration frequency is steplessly adjustable. Pre-compaction degree up to 95%
2. The longest track design ensures the best traction
3. Bo mag's innovatively designed ECOMODE energy-saving system, MAGMALIFE screed electric heating system, screed fast assembly system and SIDEVIEW system ensure the highest safety of the machine
4. The length of the screed soleplate is designed to be long to ensure the best paving surface flatness
5. Proportionally controlled spiral distributor and scraper feeder, equipped with ultrasonic sensor
6. Load control system of screed (L.C.S.)
7. Hydraulic foldable awning and screed are quickly locked, all of which make transportation safer and easier
