• Model NO.：Shantui SD52
• Condition：New
• Color：Yellow
• Operating Weight：67.5ton
• Rated Power：392kw
• Blade Width：4695*2265mm
• Engine Emission Standard：Euro 3
• Transport Package：Nude Packing
• Specification：CE
• Trademark：Shantui
• Origin：Shandong
• Production Capacity：100set,Months

L×W×H(Ripper not included)
mm
10420×4680×4470 (Ripper included)
Operating weight(Ripper not included)
t
67.5(Ripper included)
Engine
-
 QSK19
Engine Emission standard
-
Euro III
Rated power
kW/rpm
392/1800
Gradeability
°
30
Blade type
-
Semi-U blade
Blade width
mm
4695×2265
Dozing capacity
m3
18.5
Ma× drop below ground of blade
mm
720
Lift height of blade
mm
1660
Ripper type
-
Single ripper
Ripping depthof ripper
mm
1435
Lifting height of ripper
mm
1105
Number of carriers (each side)
-
2
Number of track rollers (each side)
-
7
Number of track shoes (each side)
-
40
Width of track shoe
mm
610
Track gauge
mm
2500
Ground length and ground pressure
mm/MPa
3940-0.138
Pitch
mm
280
Forward speed
km/h
0-3.8
0-6.8
0-11.8
Reverse speed
km/h
0-5.1
0-9.2
0-15.8
