• Model NO.：SR16
• Travel Speed：30cm,s
• Centrifugal Force：30.5KN
• Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Transport Package：Nude Package
• Specification：6240*2300*3100mm
• Trademark：Shantui
• Origin：China
• HS Code：8429401100
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. SR16 Travel Speed 30cm/s Centrifugal Force 30.5KN Certification CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Transport Package Nude Package Specification 6240*2300*3100mm Trademark Shantui Origin China HS Code 8429401100 Production Capacity 50000PCS/Year

Product Description

Driving/Riding Environment

The drive mode adopts hydrostatically driven traveling and (front and rear drums) double drive to achieve stronger gradeability. The speed changeover is electronically controlled to realize easy, simple, and comfortable operations. The two-speed stepless speed regulation guarantees the working at most appropriate speed under diversified working conditions.

The articulated full-hydraulic steering system features flexible and convenient steering. The steering gear adopts U.S. Eaton product and incorporates FK combination valve to achieve high flow, low steering force, and overload protection and cushioning function.

The brake system composed of the brakes on drive axle and vibratory drum reducer and the hydrostatic brake of closed type hydraulic system incorporates the service brake, parking brake, and emergency brake functions to guarantee the driving safety and reliability.

The all-new streamline design guarantees smooth, neat, and elegant machine modeling.

With luxury upholstery, the cab in polyhedral structure features broad visual field and large space.

Parameter name	SR16
Performance parameters
Operating weight (Kg)	16000
Exciting force (KN)	335/220
Vibration frequency (Hz)	28/32
Nominal amplitude (mm)	1.60/0.65
Gradeability (%)	45
Engine
Engine model	Weichai WP6G175E22
Rated power/rated speed (kW/rpm)	129kw/2200rpm
Overall dimensions
Overall dimensions of machine (mm)
Driving performance	6240*2300*3100
Forward speed (km/h)	F1: 0-5.5, F2: 0-10
Reversing speed (km/h)	R1: 0-5.5, R2: 0-10
Chassis System
Wheelbase (mm)	3150
Tank capacity
Fuel tank (L)	280
Working device
Compacting width(mm)	2130
