Engineering & Construction Machinery

Home > Product > Loader

Good Quality 2.5ton Material Telescopic Handler with Fork and Bucket

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification：ISO
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Hydraulic
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：SWTH2570H
  • Type：Small Loader
  • Max. Lifting Height：6m
  • Dead Weight：7600kg
  • Gradeability：30%
  • Traveling Speed：28 Km,H
  • Warranty：12 Months
  • Brand：Sinoway
  • Rated Power：60kw
  • Drive Mode：4X4
  • Engine Make：Cummins
  • Transport Package：Nude
  • Specification：2.5 ton payload
  • Trademark：SINOWAY
  • Origin：China
  • HS Code：84272090
  • Production Capacity：100 PCS , Year

Description

Rated lifting capacitykg2500Lifting capacity at maximum extension kg1000Max. lifting height of basic boom mm4300Max. lifting height at full extension of the boom mm6000Max. travel speed km/h28Min. ground clearance mm310Min. turning diameter (center of outer wheel) mm12500Gradeability %30Dead weightkg7100Overall dimensions (L * W * H)Lmm5560Wmm2270Hmm2560Inner width of the cabmm740Tread mm1900Wheel basemm2520Engine Model Cummins Rated power kw60Rated speed r/min2000TyreFront  16/70-20Rear  8.25-20-14
