• Type：Medium-sized Loader

Overall Dimension1Length(with bucket on ground)7085(mm)2Width2313(mm)3Load Bucket width2313(mm)4Height(To the top of the cab)2710 (mm)5Height(To the top of the digging pole)3424 (mm)6Wheelbase2155.5(mm)7Back wheel Tread1700(mm)8Fore wheel Tread1880(mm)9Min. ground clearance355(mm) for 2WD 275(mm) for 4WDMain Loading Technical Specification1Rated load1700(Kg)2Operating weight7600KG3Max lifting capability>2500KG4Rated load bucket capacity1.0(m3)5Max. load breakout force>60kN6Max. dump clearance2714(mm)7Max. Dump reach845(mm)8Dump angle at any position≥43.5°9Min. turning radius (1) Outside of bucket5280(mm) for 2WD 5670(mm) for 4WD(2) Center of front wheel3795 (mm) for 2WD 4380(mm) for 4WD10Lifting time of loading bucket≤4.5(sec.)11Lowering time of loading bucket≤3.5(sec.)12Dumping time≤1.5(sec.)13Traveling speed(Km/h),4 forward and 4 reverse (1) I gear forward6(2) II gear forward9.6(3) III gear forward20.5(4) IV gear forward38(1) I gear reverse6.0 (2) II gear reverse9.6(3) III gear reverse20.5(4) IV gear reverse38Main Digging Technical Specification1Rated digging bucket capacity0.3(m3)2Max. digging depth4405(mm)3Max. digging force>50±10%kN4Max. digging radius5481(mm)5Max. dumping height3737(mm)Diesel engine1ModelB4.5DongFeng 4BTA3.9-C1102TypeDirect injection. Turbocharged. Water cooling3Rated power / Rated speed74 (kW) / 2200(r/min)82 (kW) / 2200(r/min)4Displacement4.5(L)3.9(L)5Inter-bore of cylinder/stroke102/138(mm)102/120(mm)6Model, Voltage and Power of starting motorST9371 12(V) 4.8(kW)ST 9501 12(V) 6(kw)7Model, Voltage and Starting Current of AlternatorEE9242 12(V) 95AmpEE 9235 14(V) 70Amp8Max. Torque414(N.M) @1500RPM460N.m@1500RPM9Starting typeElectric10Min. specific fuel consumption207(g/Kw.h) Transmission System1. Torque Converter1ModelCARRARO2Cooling typePressure oil circulating2. Transmission case1ModelCARRARO2TypeSynchromesh mechanical shift3Gear shift position4 Forward and 4 reverse gears3. Axle and Tire1ModelCARRARO2Type of main reducerspiral bevel gear, single stage3Type of final reducerSingle stage planetary4Max. steering angle55°5Tire type4WD fore tire12-16.5NHS-10PR2WD fore tire11L-16F3-12PRRear tire 19.5L-24R4-12PRWorking Device Hydraulic System1Model of oil pumpK2215(CASAPPA)2System pressure230(kgf/cm2)3Model of priority valveWALVOIL SDS180Steering System1TypeFore wheel Steering2Model of steering pumpK2215(CASAPPA)3Model of steering gear150-1219(DAIVFOSS)4System pressure140(kgf/cm2)Oil Capacity1Fuel(diesel)151(L)2Engine lubricating oil11(L)3Oil for converter and gear box18.5(L)4Oil for hydraulic system110(L)5Oil for driving axles(F/R)7.6+17(L)
