• Model NO.：SD32
• Production Capacity：3000,Month

ITEM
UNIT
SD32/SD32D
L×W×H (Ripper not included)
mm
6880×4130×2725
Operating weight (Ripper not included)
t
38
Engine
-
CumminsNTA855-C360S10
Rated power
kW/rpm
235/2000
Gradeability
°
30
Blade type
-
Straight tilt blade
Blade width
mm
4130×1590
Dozing capacity
m3
10
Ma× drop below ground of blade
mm
560
Lift height of blade
mm
1560
Ripper type
-
Single ripperThree-shank ripper
Ripping depth of ripper
mm
Single ripper 1250Three-shank ripper 842
Lifting height of ripper
mm
Single ripper 955Three-shank ripper 883
Number of carriers (each side)
-
2
Number of track rollers (each side)
-
7
Number of track shoes (each side)
-
41
Width of track shoe
mm
560
Track gauge
mm
2140
Ground length and ground pressure
mm/MPa
3150-0.105
Pitch
mm
228.6
Forward speed
km/h
0-3.6
0-6.6
0-11.5
Reverse speed
km/h
0-4.4
0-7.8
0-13.5
