• Model NO.：RD240
• Vibrating Amplitude：1.4mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Green
• Rated Capacity：240t,H
• Cold Hopper Quantity：5
• Cold Hopper Volume：10m3
• Standard Burner：Oil Burner
• Oil Consumption：6.5kg,T
• Screen：5layers
• Mixer Capacity：3000kg,Batch
• Powder Temporary Storage Capacity：0.7m3
• New Filler Silo：40m3
• Dimension：42mx30mx18m
• Transport Package：Container or RO-RO or Bulk Ship
• Specification：ISO, CE
• Trademark：ROADY
• Origin：Nanyang, Henan
• HS Code：84743900
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. RD240 Vibrating Amplitude 1.4mm Certification ISO9001: 2000, CE Condition New Color Green Rated Capacity 240t/H Cold Hopper Quantity 5 Cold Hopper Volume 10m3 Standard Burner Oil Burner Oil Consumption 6.5kg/T Screen 5layers Mixer Capacity 3000kg/Batch Powder Temporary Storage Capacity 0.7m3 New Filler Silo 40m3 Dimension 42mx30mx18m Transport Package Container or RO-RO or Bulk Ship Specification ISO, CE Trademark ROADY Origin Nanyang, Henan HS Code 84743900 Production Capacity 50000PCS/Year

Product Description

Rd240 Asphalt Mixing Plant
Modular cold aggregate feeding system which can synchronization proportional control and adjust automaticly
 Energy-efficient dry heating systems whose heat exchange efficiency reach 90%
 High-strength plate chain bucket elevator system with 0 db mute backstop
 Quick changing and maintenance-free screening system with smart air lead and pressure relief
 High precision weighing system with good stability and automatically error compensation
 High efficiency and large-circulation stereo boiling mixing system with 15% overcapacity redundant design
 Efficient and environmentally friendly bag filter system with emissions Far exceeding the national standards
 Stackedfiller silo with customized items available, reclaimed filler re-using system
 Asphalt supply system with easy and flexible combination and fast installation
 High reliability air system which can continuous working in extreme environment with -15ºC-50ºC
 Stable and easy operationPC+PLC smart control system with independent intellectual property rights

Technical Specification	RD240
Rated capacity	240t/h
Cold hopper quantity	5
Cold hopper volume	10m³
Standard burner	Oil burner
Oil Consumption	6.5kg/t
Screen	5layers
Mixer capacity	3000kg/batch
Powder temporary storage capacity	0.7m³
New filler silo	40m³
Old filler silo	25m³
Finished warehouse capacity	Optional
Asphalt tank	3x50 m³
Heavy oil tanks	2x50m³
Light oil tanks	1x10m³
hot oil stove	7.5x104
The total installedpower	621.92kW
Dimension	42mx30mx18m
