• Model NO.：CLG856 5TON
• Type：Medium-sized Loader
• Transport Package：Nude Packing, Suitable for Shipment
• Specification：8150*2975*3467mm
• Trademark：LIUGONG
• Origin：China

ENGINE

LOADER ARM PERFORMANCE

Emission Regulation

Tier 2 / Stage II

Tipping Load - Straight

13,200 kg

Make

DCEC

Tipping Load - Full Turn

11,750 kg

Gross Power

164 (220 hp) kW@2,200 rpm

Bucket Breakout Force

158 kN

Net Power

147.6 (198 hp) kW@2,200 rpm

Maximum Dump Angle at Full Height

45°

Peak Torque

950 N ·m @ 1,300 rpm

Dump Clearance at Full Height Discharge

3,100 mm

Displacement

8.9 L

Dump Reach at Full Height Discharge

1,035 mm

Number of Cylinders

6

Maximum Hinge Pin Height

4,154 mm

Aspiration

turbo air-to-air aftercooled

Maximum Digging Depth, Bucket Level

 52 mm

TRANSMISSION

Bucket Rollback at Ground Level

45 °

Transmission Type

countershaft power shift

Bucket Rollback at Carry

50 °

Torque Converter

single-stage, three-element

Bucket Rollback at Maximum Height

61 °

Maximum Travel Speed, fwd

37 km/h

BUCKET PERFORMANCE

Maximum Travel Speed, rev

23 km/h

Reference  Bucket

3 m3

Number of Speeds, fwd

4

DIMENSIONS

Number of Speeds, rev

3

Length with Bucket Down

8,150 mm

AXLES

Width Over Tires

2,750 mm

Differential Front Type

limited slip

Wheelbase

3,250 mm

Differential Rear Type

limited slip

Wheel Tread

2,150 mm

Axle Oscillation

±14 °

Ground Clearance

431 mm

STEERING

Turn Angle, Either Side

38 °

Steering Configuration

articulated

Rear Angle of Departure

30 °

Steering Relief Pressure

16 MPa

Turning Radius, Outside of Tire

6,232 mm

BRAKES

Turning Radius, Center of Tire

5,932 mm

Service Brake Type

wet multi disc

Turning Radius, Bucket Carry

6,913 mm

Service Brake Actuation

hydraulic

TIRES

Parking Brake Type

auto/manual pneumatic control

Tire  Size

23.5 - 25

Parking Brake Actuation

spring apply; hydraulic release

OPERATING WEIGHTS

HYDRAULIC SYSTEM

Operating Weight

17,100 kg

Main Pump Type

gear

SERVICE CAPACITIES

Main Relief Pressure

20 MPa

Fuel Tank

330 L

Raise

6s

Engine Oil

30 L

Dump Time

1.5s

Cooling System

58 L

Float Down Time

3 s

Hydraulic Reservoir

210 L

Fastest Total Cycle Time

10.5s

Transmission and Torque Converter

45 L

Axles, each

34 L
