Skid Steer Loader Jc45 (Rated Capacity 700KG)
Hubei Suny Automobile and Machinery Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Type：Large Loader
- Rated Load Capacity：700kgs
Base Info
- Model NO.：JC45
- Usage：Universal Type
- Scraper Type：Pull Scraper
- Load and Unload Method：Front Discharge
- Engine Power：<74kw
- Color：Yellow
- Transport Package：in Nude
- Specification：ISO
- Trademark：SUNY
- Origin：China
- HS Code：84295100
- Production Capacity：1000 Units
Description
Basic Info.
Model NO. JC45 Usage Universal Type Scraper Type Pull Scraper Load and Unload Method Front Discharge Engine Power <74kw Color Yellow Transport Package in Nude Specification ISO Trademark SUNY Origin China HS Code 84295100 Production Capacity 1000 UnitsProduct Description
Introduction of JC45 skid steer loader
Xinchang brand diesel engine model 490BPGImported hydraulic system Open cabin with mechanical control systemDouble accelerograph controlHydraulic brakeSpecification of JC45 skid steer loader
| Item | Description | Item | description |
| Rated operating capacity(kg) | 700 | Hinge pin height (mm) | 2900 |
| Tipping load (kg) | 1400 | Total height (mm) | 2050 |
| Bucket capacity(m3) | 0.36-0.45 | Length with bucket (mm) | 3380 |
| Hydraulic pump flow (L/min) | 62.5 | Length without bucket(mm) | 2450 |
| Engine power (hp) | 50 | Width with bucket (mm) | 1740 |
| Weight(kg) | 2750 | Track width (mm) | 1450 |
| Max travel speed (km/h) | 12 | Wheelbase (mm) | 991 |
| Grade ability | 20 | Ground clearance (mm) | 185 |
| Tire | 10-16.5 | Dumping angle | 40 |
| Fuel/hyd oil capacity (L) | 50/50 | Dumping height (mm) | 2310 |
| Height at maximum extension | 3670 | Maximum reach (mm) | 710 |
