Qjstwin Shaft Electric Concrete Mixer Machine\Js Series Concrete Mixer
Qunfeng Intelligent Machinery Co., Ltd.- Type：Concrete Mixer
- Shotcrete Type：Semi-Dry
- Machining Process：Two Shaft
- Structure：Rotor Type
- Productivity：50m²,h
- Feeding Height：1370mm
Base Info
- Model NO.：QJS500, QJS750, QJS1000
- Vibrating Amplitude：0.8mm
- Certification：ISO9001: 2000, CE, ISO9001: 2000, CE, SGS
- Condition：New
- Method：Mixing
- Processing：Concrete Mixing
- Product：Concrete
- Transport Package：Standard Packing
- Specification：JS500, JS750, JS1000
- Trademark：QUNFNEG
- Origin：Fujian, China
- HS Code：847431
- Production Capacity：1000sets,Year
Description
| Model | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 | |
| Feeding Capacity | 1600L | 2400L | 3000L | 4800L | 6000L | |
| Exceeding Capacity | 1000L | 1500L | 2000L | 3000L | 4000L | |
| Productivity | 50m3 /h | 75m3 /h | ≈120m3 /h | ≈180m3 /h | ≈240m3 /h | |
| Maximum material diameter oaggregate(pebble/crushed stone) | 80/60mm | 80/60mm | ≤150mm | ≤150mm | ≤150mm | |
| Mixing Vane | Rotate speed | 25.5r/min | 26r/min | ≈24.3r/min | ≈24.3r/min | ≈24.3r/min |
| Quantity | 2×8 | 2×8 | 14 | 16 | 20 | |
| Mixing moto | Power | 2×22kW | 2×37kW | 2×37kW | 2×55kW | 2×75kW |
| Lubrication oil pump | Power | 0.05kW | 0.05kW | 0.09kW | 0.09kW | 0.09kW |
| Hydraulic oil pump | Power | 2.2kW | 2.2kW | 2.2kW | ||
| Dimension | Working | 8280×3150 ×7920mm | 10540×3800 ×10140mm | 3275×2320 ×2227mm | 3771×2600 ×2225mm | 4469×2600 ×2225mm |
| Conveying | 5500×2150 ×1800mm | 7000×2300 ×2350mm | ||||
| Weight | 10000kg | 13500kg | 7500kg | 9200kg | 11800kg | |
| Model | JS750 | JS500 | |
| Feeding Capacity | 1200L | 800L | |
| Exceeding Capacity | 750L | 500L | |
| Productivity | ≥35m3/h | ≥25m3/h | |
| Max.diameter of principal material | 80/60mm | 60/40mm | |
| Mixing Vane | Rotate speed | 30.5r/min | 35r/min |
| Quantity | 2×7 | 2×7 | |
| Power | 38.8kW | 25.3kW | |
| Dimension | Working | 4970×3330×6520mm | 5140×3000×5600mm |
| Conveying | 4500×2250×2470mm | 3500×2260×2380mm | |
| Weight | 6800kg | 4000kg | |
Global service system
As a model enterprise of China building material machinery, Qunfeng provides upscale and high-quality machinery with intelligent technology for their customers. Covering six continents with 7 overseas service stations and 24 domestic offices, Qunfeng has served 9000 clients from 110 countries and regions with more efficient intelligent manufacturing equipment. Qunfeng has earned great reputation in the world with its products being exported to high-level market worldwide, include Asia, Europe, South America, Oceania, Africa and North America.
