• Model NO.：ST1200
• Travel Speed：35cm,s
• Centrifugal Force：27KN
• Certification：EPA, CE, ISO 9001:2000
• Condition：New
• Engine：Diesel Changchai 192f,Honda Gx390
• Drum Width：800mm
• Drum Diameter：560mm
• Steering Method：Hydraulic Steering
• Fuel Tank Capacity：5.5L
• Water Tank Capacity：65L
• Hydraulic Oil Tank：22L
• Walking Speed：0-5 Km,H
• Weight：1200kg
• Climbing Ability：30%
• Transport Package：Wooden Package
• Specification：2030*980*1700mm
• Origin：China
• HS Code：8429401900
• Production Capacity：5000 Set,Year

ST1200 ROAD ROLLER is mainly used to compress on the asphalt, sand soil and gravel. It is also used to compress on track in the school and planish the lawn. This is the latest model of light duty rollers in the domestic.

Product characteristics

Double motors drive, hydraulic steering and vibrate, fully hydraulic roller.

1. Imported Sauer hydraulic variable plunger pump, drives the machine stepless speed walking.

2. Double Poclain plunger motors drive the machine walking.

3. Imported brand motor drives the steel drum vibrating.

4. Extra-large plastic water tank, free from corrosion and convenient for the water-spraying.

5. Double control levers with vibration button, makes the compaction of edge easy.

6. Electrically controlled water-spray, high efficient and water-saving.

7. Wear-resistant scraper can be lift and fixed during transportation.

8. LED lamp at front and rear for the convenience of night construction.

 EngineBRIGGS&STRATTON  25T2/Honda GX390CHANGCHAI  192FEngine typeSingle cylinder, OHV, air-cooled, four-stroke, gasolineSingle cylinder, vertical, air-cooled, four-stroke, dieselNumber of cylinders1Output power (KW)9.78.1Rating speed(RPM)3600Fuel consupmtion(G/KWH)313320Lubricating oil volume(L)1.11.65DRIVING Electrical equipment(V)12Drive modeVariable plunge pump, stepless speed change, double-wheel series, parallel motorWalking speed (KM/H)0--5Theoretical climbing ability(%)30/35(vibration on/off)STEERING Swing angle(°)28Steering modeHydraulic cylinder, articulated steeringSteering systemSwing articulatedEXCITING SYSTEM Vibration wheelFrontDrive formHydraulic MotorsVibration frequency (HZ)65Vibration amplitude (MM)0.5Exciting force(KN)22SPRINKLING SYSTEM Water spray formIntermittent pressure water sprayCAPACITY Hydraulic oil capacity(L)22Fuel capacity(L)6.55.5Water tank capacity (L)65SIZE Working width(MM)930Overall length(MM)1980Machine height(MM)1540Turning radius(outer)(MM)3165Ground clearance(MM)245Wheel track(MM)1356Drum size560*800mm*2Drum thickness(MM)12WEIGHT Weight(KG)1200Static load(N/CM)69.5/68
Feedback from clients:


Packaging & Shipping


Company Information:

Shandong Storike Engineering  Machinery Co., Ltd is specialized in the sales and production of small road roller, compact ram, mobile lighting car, hydraulic power station, troweling machine and other construction machine. Our products are widely used in municipal and highway pavement road roller maintenance, small area compacting and depressed trough and so on. Our equipment is favored by many construction companies and have a large market in China. More and more trading companies purchase equipment from our plants, so we decide to enter world market with more favorable price to shape our product brand and provide the best after-sale service. If you are interested in our machine, contact us!
