Intermot Nhm (NAM) Low Speed Hydraulic Motor
Ningbo Kingbonny Machinery Imp. & Exp. Co., Ltd.- Displacement：213-10019 Ml,R
- Torque：935-36667 N.M
- Replace Nhm Hydraulic Motor：Nam 1 Series
- Transport Package：Plywood Case
- Specification：ISO 9001: 2008
- Trademark：Bonny Hydraulic
Base Info
- Model NO.：NHM1
- Origin：China
- HS Code：8412291000
- Production Capacity：1000sets Per Month
Description
Weight
(kg)Rated Pressure Max Pressure Rated Torque Specific Torque
(N.m/MPa) NAM1-63 77 25 32 284 11 15-1500 20
(kg)
(N.m/MPa)
| Model | Displacement (ml/r) | Rated Press (Mpa) | Peak Press (Mpa) | Rated Torque (N.m) | Spec.Torque (N.m/Mpa) | Speed Range (r/min) | Weight (kg) |
| NAM2-100 | 113 | 25 | 32 | 420 | 18 | 15~1250 | 27 |
| NAM2-150 | 159 | 25 | 32 | 620 | 25 | 15~1000 | 27 |
| NAM2-175 | 180 | 20 | 25 | 526 | 28 | 15~1000 | 27 |
| NAM2-200 | 206 | 20 | 25 | 600 | 32 | 8~800 | 27 |
| NAM2-250 | 235 | 16 | 20 | 607 | 40 | 8~630 | 27 |
| NAM2-280 | 276 | 16 | 20 | 670 | 44 | 8~500 | 27 |
| NAM3-175 | 181 | 25 | 32 | 710 | 28 | 8~1000 | 35 |
| NAM3-200 | 201 | 25 | 32 | 800 | 32 | 8~800 | 35 |
| NAM3-250 | 254 | 25 | 32 | 949 | 40 | 8~630 | 35 |
| NAM3-300 | 289 | 20 | 25 | 864 | 46 | 6~500 | 35 |
| NAM3-350 | 340 | 20 | 25 | 1040 | 55 | 6~400 | 35 |
| NAM3-400 | 380 | 16 | 20 | 949 | 63 | 6~400 | 35 |
| NAM3-450 | 450 | 16 | 20 | 1054 | 71 | 6~400 | 35 |
| NAM3-500 | 493 | 16 | 20 | 1256 | 79 | 6~400 | 35 |
| NAM6-400 | 397 | 25 | 32 | 1483 | 63 | 5~630 | 57.5 |
| NAM6-450 | 452 | 25 | 32 | 1638 | 72 | 5~630 | 57.5 |
| NAM6-500 | 491 | 20 | 25 | 1463 | 78 | 5~500 | 57.5 |
| NAM6-600 | 594 | 20 | 25 | 1775 | 94 | 4~500 | 57.5 |
| NAM6-700 | 683 | 16 | 20 | 1633 | 103 | 4~400 | 57.5 |
| NAM6-750 | 754 | 16 | 20 | 1760 | 110 | 4~320 | 57.5 |
| NAM6-800 | 804 | 16 | 20 | 1884 | 128 | 4~320 | 57.5 |
| NAM6-850 | 862 | 16 | 20 | 2020 | 137 | 4~320 | 57.5 |
| NAM6-900 | 896 | 16 | 20 | 2097 | 142 | 4~320 | 57.5 |
| NAM11-700 | 682 | 25 | 32 | 2667 | 114 | 4~400 | 94 |
| NAM11-800 | 782 | 25 | 32 | 2959 | 120 | 4~400 | 94 |
| NAM11-900 | 894 | 25 | 32 | 3480 | 140 | 4~400 | 94 |
| NAM11-1000 | 981 | 20 | 25 | 2974 | 158 | 3~320 | 94 |
| NAM11-1100 | 1104 | 20 | 25 | 3336 | 177 | 3~320 | 94 |
| NAM11-1200 | 1234 | 16 | 20 | 3512 | 187 | 3~320 | 94 |
| NAM11-1300 | 1301 | 16 | 20 | 3080 | 197 | 3~250 | 94 |
| NAM11-1400 | 1401 | 16 | 20 | 3323 | 223 | 3~250 | 94 |
| NAM16-1400 | 1413 | 25 | 32 | 5138 | 210 | 2~400 | 170 |
| NAM16-1600 | 1648 | 20 | 32 | 6158 | 262 | 2~400 | 170 |
| NAM16-1800 | 1814 | 20 | 25 | 5433 | 283 | 2~320 | 170 |
| NAM16-2000 | 2034 | 16 | 25 | 6030 | 323 | 2~320 | 170 |
| NAM16-2400 | 2401 | 16 | 20 | 5763 | 360 | 2~250 | 170 |
| NAM31-2500 | 2553 | 25 | 32 | 9523 | 405 | 2~250 | 298 |
| NAM31-2800 | 2683 | 25 | 32 | 10559 | 443 | 1~200 | 298 |
| NAM31-3000 | 3063 | 20 | 25 | 9135 | 485 | 1~200 | 298 |
| NAM31-3150 | 3218 | 20 | 25 | 9392 | 500 | 1~200 | 298 |
| NAM31-3500 | 3462 | 20 | 25 | 10220 | 544 | 1~160 | 298 |
| NAM31-4000 | 4152 | 20 | 25 | 12481 | 665 | 1~160 | 298 |
| NAM31-5000 | 4828 | 16 | 20 | 12387 | 825 | 1~160 | 298 |
