• Model NO.：TL30
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Rated Speed：2200r,Min
• Service Brake：Air-on-Oil, Caliper-Disk
• Hydraulic：80L
• Power(W)：92kw
• Max. Speed：36km,H
• Main Transmission Type：Spiral Gear, First Stage Decelerate
• Overall Working Weight：8000kg
• Max. Tractive Force：65kn
• Transmission Type：Planetary Power Shift
• Fuel：80L
• Boom Lifting Time：6s
• System Working Pressure：16MPa
• Total Time：11s
• Mini Turning Radius：5200mm
• Torque ratio：3.2
• Transport Package：Nude in Container
• Specification：647X212X296 cm
• Trademark：TITAN
• Origin：China
• HS Code：84295100
• Production Capacity：1000,Year

ITEMSPECIFICATIONITEMSPECIFICATIONOverall working weight8000kgMax. speed36Km/hRated load3000kgMain transmission typeSpiral gear, first stage decelerate
 Max. tractive force65KNTyre specification17.5-2Max. breakout force≥65KNFront tyre pressure275KPaMax. gradeability30°Rear tyre pressure275KPaMax. dumping height3500mm
 TypeArticulated load-sensing hydraulic steering system
 Dumping distance950mmSteering angle±35°Overall dimension (L×W×H)6470×2120×2960mmMini turning radius
 5200mm
 ModelWeichai WP6G160E20system working pressure16MPaTypeInline, water cooling, dry cylinder, direct injectionBoom lifting time6sNumber of cylinder-bore/stroke6-108×125mm
 Total time
 11sRated power92kWRated speed2200r/minTransmission typePlanetary power shiftService brakeAir-on-oil, caliper-diskGrear shift4 forwardshift, 4 reverseshiftparking brakeManual caliper discFuel80LTorque converterSingle-stageHydraulic80LTorque ratio3.2



 FAQ

Q:Why choose Titan?
We sell every machine at a fair price.As our production increases,we are getting much support from the purchase source of raw meterial.
We leave the maximum profit to customer.
1) Titan: an experienced loader manufacturer with over 11 years.
2) Titan TEAM: customers-focused,you'll get reply within 5 minutes.
3)Titan: premium quality with reasonable price.
4) Titan: CE,BV,SGS,ROPS and FOPS,ISO9001:2008 varified.
The quality control is not an empty word in TITAN.Our products are tested and granted CE certificate.

Q:What is Titan warranty?
TITAN has a professional sales and after-service team.We are trying our best to make a good service for every customer.
1) Titan after-sales: life-long, meantime offer one year and one month warranty.
2) Titan proposal: order some wearing parts with loader for easy maintenance.

Q:What about Titan delivery term?
TITAN Transport packsging team helps our customer to transport their machine in safe and secure way without any damage.
10-14 days after down payment received.

Q:What about the payment term?
30% advance payment,70% balance by T/T.
