• Model NO.：LG918
• Type：Small Loader
• Wheel Base：2260mm
• Max. Dumping Height：2510mm
• Min Turning Radius：4460mm
• Bucket Capacity：1.0-1.4m3
• Operating Weight：6150kg
• Max. Breakour Force：58kn
• Engine Brand：Yuchai
• Engine Model：Yc4d80-T20
• Engine Power：58kw
• Transport Package：Container, RO-RO
• Specification：5790*2140*2920mm
• Trademark：SDLG
• Origin：Linyi, Shandong, China
• Production Capacity：50000unit,Year

Basic configurationEngine Yuchai YC4D80-T20Transmission systemFixed shaft power shift, SDLG reinforced drive axleHydraulic system    Pilot controlLift armStandardControl valve2-joint valveBrake systemDual brake  pedalCab Standard Heating  & CoolingAir conditionerOther configurationStart interlock Engine  tachometer Hose for inflating tyre Fuel tank lockDetailed configurationOverall dimensionL*W*H5790*2140*2920mmWheel base2260mmMin. ground clearance290mmMax. dumping height2510mmLifting height3200mmDumping distance920mmDumping angle45°wheel tread1630mmsteering angle35°horizontal crossing radius5082mmMin. turning radius4460mmOverall parametersBacket capacity1.0m3(1.0-1.4)Rated load1800kgoperating weight6400kgMax. tractive force56kNMax. breakout force58kNTipping load36kNEngineModelYC4D80-T20Typewatercooled, four-stroke, direct injectionRated power58kWRated speed2400r/minEngine displacement4214mlMax. torque265N.mEmission standardGB 20891-2007Min. fuel-consume ratio235g/kw.hTransmission systemTorgue convertersingle-stage three-element hydraulic torque converterTransmission typeFixed shaft power shift+high/low speedGearsForward 2 reverse 2Hydraulic system of working deviceTypeHydraulic pilot controltotal time9.1sBrake systemService brake typeAir over hydraulic disc typeParking brake typeManual control internal expanding shoe brakeSteering systemTypeLoad sensing full hydraulic articulated steeringSystem pressure12 MpaFill capacityFuel120LHydraulic oil100LEngine13LTransmission20LDrive axleForward 10L+ reverse 10LBraking system4L
