• Model NO.：YLB1400
• Product Name：Hydraulic Breaker Hammer
• Chisel Diameter：140mm
• Oil Hose Diameter：1inch
• Color：Yellow or as Per Customers′ Request
• Suitable Excavator：20-26ton
• Quality：Korean Quality
• Chisel Type：Moil Point Type, Blunt, Wedge Type......
• Required Oil Flow：130-170L,Min
• Impact Energy：4200joule
• Transport Package：Standard Export Package,as Per Customers′ Requet
• Specification：Material 20CrMo
• Trademark：PTEROSAUR
• Origin：Yantai China
• HS Code：8412210000
• Production Capacity：500sets,Month

Basic Info.

Model NO. YLB1400 Product Name Hydraulic Breaker Hammer Chisel Diameter 140mm Oil Hose Diameter 1inch Color Yellow or as Per Customers′ Request Suitable Excavator 20-26ton Quality Korean Quality Chisel Type Moil Point Type, Blunt, Wedge Type...... Required Oil Flow 130-170L/Min Impact Energy 4200joule Transport Package Standard Export Package/as Per Customers′ Requet Specification Material 20CrMo Trademark PTEROSAUR Origin Yantai China HS Code 8412210000 Production Capacity 500sets/Month

Product Description

S-OOSAN SB81 Hydraulic Rock Breaker Jack Hammer for Excavator

Main Features

1. Use the highest strength material to get better wearing resistance.

2. Easy maintenance, prolonged life.

3. We have accumulated sales of 20,000 units, rich maintenance experience.

Advantages

1. Selected raw material - high quality heavy duty wear resistant steel
2. Hydraulic-gas system, increase stability
3. High-quality and durable wear parts
4. Advanced manufacturing facilities, introduced from South Korea
5. High energy and impact frequency (high performance)
6. High-performance optimized hydraulic unit
7. Low maintenance, less breakdown, long using life

Specification





Description	Model	SB30	SB40	SB43	SB50	SB70	SB81	SB121	SB131
		YLB530	YLB680	YLB750	YLB1000	YLB1350	YLB1400	YLB1550	YLB1650
Operating Weight	KG	150	300	430	860	1650	1825	2850	3350
Optimum Oil Flow	L/min	25-50	40-70	50-90	80-120	100-150	130-170	170-220	200-260
Impact Rate	bpm	550-1000	500-800	450-800	350-700	350-600	350-500	300-450	250-400
Hose Diameter	inch	1/2	1/2	1/2	3/4	1	1	5/4	5/4
Rod Diameter	mm	53	68	75	100	135	140	155	165
Applicable Carrier	ton	2.5-4.5	4-7	6--9	11-16	18-21	20-26	28-35	30-40
Valve Ass'y Position	/	internal	internal	internal	internal	internal	internal	internal	internal

Our company

YANTAI BAICAI Hydraulic breakers, we have three types for your choice:  Side Type,Top Open type, and Box Silenced Type.
YANTAI BAICAI Hydraulic breakers Advantages:
1. High Strength and wear resistance steel plate adopted.
2. Suitable with all brands of excavators.
3. Strong compatibility.
4. Unique valve system. series Hydraulic Breakers adopt simple hydraulic circuit system, which use oil less and improve efficiency more.
5. First-class quality: Korean technology used to guarantee the quality.
6.Powerful stroke. Compared with other brand's products, series Hydraulic Breakers has more powerful stroke and reliable performances.

Exhibition







Package

1. Inner is stretch film
2. Outside is export wooden case
3. As per customer's request



FAQ

1. Are you a manufacturer?
Yes, our factory was established in 2004

2. Can you produce according to customers' design?
Sure, OEM / ODM service available. We are professional manufacturer for nearly 10 years.

3. What's the MOQ and payment terms?
MOQ is 1 set. Payment via T/T, L/C, Western Union accepted, other terms can be negotiated.

4. How about delivery time?
3-7 working days from the date of receiving full payment.

5. After-sale Service
14 months warranty for hydraulic breakers. 24 hour prompt after-sales service to meet your demands.

6. OEM accept
Yes, we will provide high quality products with competitive price.

7. Impact Test
Every hydraulic breaker will do impact test before sale .

Contact Information

Please tell us your excavator or backhoe loader model,or the hydraulic breaker which you want then I will send you our quotation.

Contact: Nina
