• Model NO.：L26-B3
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Operating Weight (Kg)：6200
• Dumping Reach (mm)：850 (Standard Boom) 865 (Long Boom)
• Maximum Breakout Force (Kn)：55
• Total Cycle Time (S)：8
• Engine Model：Lr4b3
• Rated Power/Rated Speed (Kw/Rpm)：62.5,2200
• Forward Speed (Km/H)：F1:0-8, F2:0-11.5, F3:0-20, F4:0-28
• Reversing Speed (Km/H)：R1:0-10, R2:0-24
• Wheelbase (mm)：2270
• Fuel Tank (L)：105
• Rated Loading Capacity (T)：2
• Rated Bucket Capacity (Cbm)：1
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：6120*2078*2850
• Trademark：shantui
• Origin：China
• HS Code：8429521200
• Production Capacity：300piece,Month

Basic Info.

Model NO. L26-B3 Load and Unload Mode Front Discharge Walking Mode Wheeled Type Small Loader Operating Weight (Kg) 6200 Dumping Reach (mm) 850 (Standard Boom) 865 (Long Boom) Maximum Breakout Force (Kn) 55 Total Cycle Time (S) 8 Engine Model Lr4b3 Rated Power/Rated Speed (Kw/Rpm) 62.5/2200 Forward Speed (Km/H) F1:0-8, F2:0-11.5, F3:0-20, F4:0-28 Reversing Speed (Km/H) R1:0-10, R2:0-24 Wheelbase (mm) 2270 Fuel Tank (L) 105 Rated Loading Capacity (T) 2 Rated Bucket Capacity (Cbm) 1 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 6120*2078*2850 Trademark shantui Origin China HS Code 8429521200 Production Capacity 300piece/Month

Product Description

 Shantui Mini Wheel Loader L26-B3 With 1Cbm Bucket Capacity In Stock


---------------------------------------
CHARACTERISTICPower System

YTO LR China-III low-speed engine features low malfunction rate, low noise, and low fuel consumption under composite working condition.

Good site adaptability

The fixed shaft 428 transmission with 4 forward gears and 2 reverse gears achieves more extensive site adaptability.

Good heat dissipation performance

The number of engine fan blades is adjusted from 7 to 9 to increase the airflow output by 10~15% and achieve better heat dissipation performance. The radiator structure is adjusted to eliminate overheating during long-distance driving and further broaden the application scope.

Optimization of hydraulic system

The series connection sequence of the multi-way valve core is adjusted in such manner that the boom lifting priority is changed to bucket tilting priority to better coincide with the actual working situation.

PARAMETER

Parameter name	L26-B3 SG (Sandstone version)	L26-B3 CH (Coal version)	L26-B3 MW(Mining version)
Performance parameters
Operating weight (Kg)	6200	6200	5600
Maximum dumping height (mm)	2460 (Standard boom)2850 (Long Boom)	2700 (Long Boom)	2460 (Standard boom)
Dumping reach (mm)	850 (Standard boom) 865 (Long Boom)	1000 (Long Boom)	850 (Standard boom)
Maximum breakout force (kN)	55	50	55
Total cycle time (s)	8	8	8
Engine
Engine model	LR4B3	LR4B3	LR4B3
Rated power/rated speed (kW/rpm)	62.5/2200	62.5/2200	62.5/2200
Overall dimensions
Overall dimensions of machine (mm)	6120*2078*2850	6210*2078*2850	5590*2078*2450
Driving performance
Forward speed (km/h)	F1:0-8, F2:0-11.5, F3:0-20, F4:0-28	F1:0-8, F2:0-11.5, F3:0-20, F4:0-28	F1:0-10, F2:0-24
Reversing speed (km/h)	R1:0-10, R2:0-24	R1:0-10, R2:0-24	R1:0-10, R2:0-24
Chassis System
Wheelbase (mm)	2270	2270	2270
Tank capacity
Fuel tank (L)	105	105	105
Working device
Rated bucket capacity (m³)	1	1.5	1
Rated loading capacity (t)	2	2	2
