• Model NO.：Changlin ZL50H
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Dimension：6863*2305*2460mm
• Rated Power：87kw
• Bucket Capacity：1.7m³
• Rated Load：5ton
• Max. Breakout Force：160kn
• Transport Package：Nude Packing
• Specification：CE
• Trademark：Changlin
• Origin：Jinan, Shandong
• HS Code：8429510000
• Production Capacity：100set,Months

Overall Dimension
1
Length(with bucket on ground)
Aerican engine
C6121 engine
8365(mm)
8215mm
2
Width(to outside of wheels)
2800(mm)
3
Bucket width
2946(mm)
4
Height(To the top of the cab)
3450(mm)
5
Wheel base
3350(mm)
6
Tread
2200(mm)
7
Min. ground clearance
450(mm)
Main Technical Specification
1
Rated load
5000(Kg)
2
Operating weight
16300KG
3
Rated bucket capacity
3.0(m3)
4
Max. breakout force
160kN
5
Max. dump clearance
3050(mm)
6
Dump reach
1107(mm)
7
Dump angle at any position
≥450
8
Digging depth(with bucket bottom horizontal)
165(mm)
9
Min. turning radius

(1) Outside of bucket
6675(mm)
(2) Outside of rear wheel
5879(mm)
10
Pivot angle frame
400
11
Oscillating angle of rear axle
+13o
12
Lifting time of bucket
≤5.8(sec.)
13
Lowering time of bucket
≤3.8(sec.)
14
Dumping time
≤1.2(sec.)
15
Traveling speed(Km/h),3 forward and 3 reverse

(1) 1st gear
7.05/9.0
(2) 2nd gear
11.7/16.0
(3) 3rd gear
34.6/38.24
Diesel engine
1
Model
6CT AA 8.3-C215 (TIER2)
ShangChai C6121 engine
2
Type
Direct injection. Turbocharge. Water cooling
3
Rated output
160 (kW)
158(Kw)
4
Inter-bore of cylinder/stroke
114/135 (mm)
121/152(mm)
5
Total exhaust of cylinder
8.3 (L)
10.5(L)
6
Model of starting motor
42MT
KB-24V
7
Power of start motor
8.2(KW)
7.5(KW)
8
Voltage of starting motor
24(V)
24(V)
9
Rated speed
2200(r/min)
2200(r/min.)
10
Max. Torque
998(N.M)
>843(N.m)
