Diesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rg

HUNAN BANGBO MACHINERY CO., LTD.
  • After-sales Service:Provide
  • Warranty:One Year
  • Type:Concrete Pump
  • Shotcrete Type:Wet
  • Machining Process:Hydraulic
  • Structure:Cylinder Type

Base Info

  • Model NO.:HBCJ40.8.62RG
  • Productivity:40m3,H
  • Feeding Height:1080mm
  • Vibrating Amplitude:2.6mm
  • Certification:ISO9001: 2000
  • Condition:New
  • Color:Red
  • Power:62 Kw
  • Max Therotic Output:40m3,H
  • Max Therotic Horizontal Distance:260m
  • Max Vertical Therotic Distance:70m
  • Drum Mixer Volume:Drum Jzc450
  • Max Pumping Discharge Pressure:8 MPa
  • Power Type:Diesel
  • Distribute Valve:S Valve
  • Cooling Form:Water,Air Cooling
  • Incharger Hopper Volume/Filling Height:650*1080 mm
  • Max Dia. of Aggregates(Cobble/Macadam):40,30mm
  • Outlet Opening Diameter:180mm
  • Inner Dia of Delivery Pipe:125mm
  • Incharge Hopper Volume:650L
  • Weight:11580kg
  • Transport Package:Roro Ship, Cargo Bulk Ship
  • Specification:7285*2200*3300mm
  • Trademark:BANGBO
  • Origin:China
  • HS Code:8413190000
  • Production Capacity:50 Set,Sets Per Month

Description

Model numberHBCJ40.8.62RGMade year2021Power TypeDieselDrum mixer volumeDrum JZC450Max theoretical Concrete Output40 m3/hMax Mixing volume30 m3/hEngine power62 kwMax Concrete Pressure8 MpaHorizontal delivery distance260 mVertical delivery distance70 m

Diesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rgDiesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rgDiesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rgDiesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rg


Diesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rgDiesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rg

Diesel Concrete Mixing Machine Mini Construction Machine Hbcj40.8.62rg
Q1: Are you trading company or manufacturer?

A: We are factory. We can design and manufacture products as customers' request.


Q2:How long is the warranty period ?
A:We offer 12 months warranty for the machine (main body) from the date of installation finished.

Q3: How long is your delivery time?

A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.


Q4: What is your payment method?

A: 30% of total price should be paid by T/T as down payment; 70% balance payment should be paid by T/T before delivery. We also support L/C, Western Union.


Q5: How many types of bangbo concrete mixer pumps do you have?

A: The motor ,diesel and electric.
If you need electric motor one, please let us know your power situation, such as in China, it is 380Voltege & 50 HZ. If you need diesel motor concrete mixer pump, the brand of diesel engine you like, it is Cummins or Deutz or Chinese Weichai,yuchai ?



Q6: How long and high is the pump distance?

A: We can provide 2 floors to 12 floors. Please let us know the vertical and horizontal delivery distance should reach. Or please let me know the tall building's total height.
