New China 1.1m3 1.8ton Bucket Payloader Lw180fv Mini Wheel Loader

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • After-sales Service：Suppport
  • Warranty：1 Year
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Power

Base Info

  • Model NO.：LW180FV
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled
  • Type：Medium-sized Loader
  • Model：Lw180fv
  • Bucket Capacity：0.9-1.1m3
  • Min.Clamping Diameter：5980*2060*2950mm
  • Lifting Time：5s
  • Rated Power：58,2400kw,Rpm
  • Digging Force：58kn
  • Tread：1550mm
  • Wheel Base：2300mm
  • Gradeability：28
  • Overall Weight：6.2t
  • Dumping Reach：1845mm
  • Transport Package：Null
  • Specification：5980*2060*2950
  • Trademark：MAXIZM
  • Origin：Jiangsu, China
  • HS Code：8429510000
  • Production Capacity：1000, Month

Description

Overview Product DescriptionProduct ParametersDescriptionUnitParameter valueRated operating loadkg1800Bucket capacitym³0.9-1.1Machine weightkg6200Dump clearance at maximum liftmm2650-2970Reach at maximum liftmm900-1000Wheel basemm2300Treadmm1550Max. breakout forceKN≥58Hydraulic cycle time-raises5Total hydraulic cycle times≤8.5Min. turning radius over tyresmm4470Articulation angle°35Gradeability°28Tyre size 16/70-20Overall machine dimension L*W*Hmm5980*2060*2950Model YC4D80-T20Rated Power/SpeedkW/rpm58/2400Travel speedI-gear(F/R)km/h0-9/0-9II-gear(F/R)km/h0-26/0-26
