• Model NO.：LW500FV
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Bucket Capacity：3.0m3
• Dumping Height：3100mm
• Wheelbase：2900mm
• Min. Turning Radius：6920mm
• Dimension：8530*3016*3350mm
• Transport Package：Nude
• Specification：8010*3016*3350mm
• Trademark：NEWINDU
• Origin：China
• Production Capacity：1000units,Per Year

Detailed PhotosProduct ParametersItemSpecificationUnitRated operating load5000kgBucket capacity2.5~4.5m³Machine weight16900kgDump clearance at maximum lift3150~3560mmReach at maximum lift1100~1190mmWheel base2960mmTread2250mmHeight of hinge at maximum lift height4112mmWorking height(fully lifted)5510mmMax.breakout force170kNHydraulic cycle time-raise6sTotal hydraulic cycle time10.5sMin. turning radius over tyres5950mmArticulation angle35°Gradeability28°Tyre size23.5-25-16PR Overall machine dimension L×W×H7910×3016×3515 ModelWP10G220E21 Rated Power162KwFuel Tank250LHydraulic Tank210LTravel speed1-gear(F/R)13/18km/h2-gear(F/R)40km/hPackaging & Shipping
