Model | |
---|
Model | SEM816D | SEM816D LGP | SEM816D DS | SEM816D CH | SEM816D FR |
Main Specifications | |
---|
Operating Weight | 16,900kg | 19,490kg | 19,760kg | 17,160kg | 18,580kg |
Ground Pressure | 66.8kPa | 31.1kPa | 34.8kPa | 61.8kPa | 66.9kPa |
Ground Clearance | 410mm | 410mm | 410mm | 410mm | 410mm |
Max. Slope | 30° | 30° | / | 30° | 30° |
Max. drawbar pull | |
Engine | |
---|
Engine Model | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 | WD10G178E25 |
Rated Power | 131kW | 131kW | 131kW | 131kW | 131kW |
Emission (GB/T20891-2014) | |
Type | |
Gross Power (ISO 2534) | |
Net Power (ISO 9249) | |
Max. Net Power (ISO 9249) | |
Rated Speed | |
Max. Altitude at Full Power | |
Working Tool | |
---|
Blade Type | SU / S | LGP | LGP | U | SU Forestry / S Forestry |
Blade Capacity (ISO 9246) | |
Blade Capacity | 4.3m³ / 3.5m³ | 3.4m³ | 3.4m³ | 5.6m³ | 6m³ / 5.8m³ |
Blade Width | 3,180mm / 3,590mm | 4,410mm | 4,410mm | 3,580mm | 3,180mm / 3,590mm |
Blade Width(w/end bit) | |
Blade Height | 1,240mm / 1,165mm | 1,000mm | 1,000mm | 1,400mm | 1,625mm / 1,625mm |
Max. Blade Digging Depth | 430mm / 430mm | 470mm | 470mm | 430mm | 430mm / 430mm |
Max.Blade Lift Ground Clearance | 1,041mm / 1,041mm | 1,055mm | 1,055mm | 1,041mm | 1,041mm / 1,041mm |
Max.Output Rimpull | 280kN | 280kN | 280kN | 280kN | 280kN |
Max. Digging Depth of Ripper | 584mm | / | / | 584mm | 584mm |
Max. Clearance Under Tip | 615mm | / | / | 615mm | 615mm |
Blade Tilt Height (middle hole) | |
Powertrain | |
---|
Type | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system | dual-path, closed loop electronically controlled hydrostatic drive system |
Travel Speed-F/R | infinitely variable speeds 0-10 km/h | nfinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h | infinitely variable speeds 0-10 km/h |
Steering & Brake | hydrostatic steering; wet,multi-disc brake | hydrostatic steering; wet,multi-disc brake | hydrostatic steering; wet,multi-disc brake | hydrostatic steering; wet,multi-disc brake | hydrostatic steering; wet,multi-disc brake |
Final drive | |
Minimum Streeing Radius | 3,610mm | 3,740mm | 3,740mm | 3,610mm | 3,610mm |
Undercarriage | |
---|
Type | |
Link Pitch | |
Track Shoe Width | |
Track Shoe Type | |
Track Shoe Width-Single | 510mm | / | 950mm | 560mm | 560mm |
Track Shoe Width-APEX | / | 1,050mm | 950mm | / | / |
Track Shoe Quantity (Each side) | |
Length of Track on Ground | |
Track Shoe Quantity | 37 | 42 | 42 | 37 | 37 |
Track Length On Ground | 2,430mm | 2,925mm | 2,925mm | 2,430mm | 2,430mm |
Track Gauge | 1,880mm | 2,300mm | 2,300mm | 1,880mm | 1,880mm |
Track Roller Quantity | 6 | 7 | 7 | 6 | 6 |
Track Roller Quantity (Each side) | |
Carrier Roller Quantity | 2 | 2 | 2 | 2 | 2 |
Carrier Roller Quantity (Each side) | |
Hydraulic System | |
---|
Type | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control | center close, pilot control |
Implement Hydraulic System Pressure | 19 MPa | 19 MPa | 19 MPa | 9 MPa | 19 MPa |
Multi Shank Ripper | |
---|
Type | |
Max. Penetration (Top hole) | |
Max. Clearance Under Tip (Bottom hole) | |
Climbing angle | |
Weight | |
Single Shank Ripper | |
---|
Type | |
Max. Penetration (Top hole) | |
Max. Clearance Under Tip (Bottom hole) | |
Climbing angle | |
Shank back | |
Shank forward | |
Weight | |
Service Refil Capacities | |
---|
Fuel Tank | 320L | 320L | 320L | 320L | 320L |
Fuel | |
Cooling System | 45L | 45L | 45L | 45L | 45L |
Hydraulic Tank | 140L | 140L | 140L | 140L | 140L |
Pivot Shaft Case(each side) | 1.2L | 1.2L | 1.2L | 1.2L | 1.2L |
Engine Crankcase | 24L | 24L | 24L | 24L | 24L |
Final Drive(each side) | 30L | 40L | 40L | 30L | 30L |
