Ltmg Articulated Wheel Loader Zl50 5 Ton 6 Ton 7 Ton 8 Ton Front End Wheel Loader with Attachments

XIAMEN LTMG CO., LTD.
  • Warranty：1 Year,2000 Working Hours
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Rated Load：5, 000 Kg
  • Transmission：Hydraulic - Mechanical
  • Load and Unload Mode：Front Discharge

Base Info

  • Model NO.：LT955
  • Walking Mode：Wheeled
  • Type：Large Loader
  • Engine：Cummins or Weichai
  • Rated Power：162kw,2000rpm
  • Bucket Capacity：3 M3
  • Wheelbase：2820mm
  • Operating Weight：16, 100 Kg
  • Tire Type：23.5-25
  • Max.Dumping Height：3100mm
  • Overall Length：7460mm
  • Color：Yellow
  • Transport Package：Container or by Bulk
  • Specification：7460mm*2870mm*3220mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8429510000
  • Production Capacity：800sets,Year

Description

ModelLT955Operating weight17500 kgRated load5, 000 kgBucket capacity3 m³Engine modelWEICHAI WD10G220E23(LT953) 2000RPMRated power162KWRated rotate speed2000 r/minMax. Torque745.3N. MBreakout force145KNForward I0-11.5km/hForward II0-38km/hReverse I0-16km/hGrade ability28°Overall length7460mmOverall width2870mmOverall height3220mmBucket width3000mmWheel base2820mmTrack base2260mmMin. Ground clearance450mmMax. Dumping height3100mmMax. Dumping reach1310mmHydraulic Torque converterSingle stage, 4elementsTransmissionPlanet-typeRaise time≤6.8sTotal≤12.5sTire type23.5-25 20PR
