• Model NO.：E635F
• Size：Small-Scale
• Certification：ISO9001: 2000
• Condition：New
• Overall Operating Weight：3880kg
• Max. Digging Radius：5300mm
• Max. Digging Depth：3085mm
• Max. Digging Height：4800mm
• Engine Brand：Yanmar
• Engine Type：Water-Cooled, Four-Cylinder
• Engine Power：26.3kw
• Emission Standard：Tier III
• Min. Fuel-Consume Ratio：244G,Kw.H
• Hydraulic Control Type：Pilot Proportional Control Valve
• Hydraulic System Type：Constant Power Load Sensitive Single Pump
• Transport Package：RO-RO, Container
• Specification：2450*1620*2450mm
• Trademark：SDLG
• Origin：Linyi, Shandong, China
• Production Capacity：50000unit,Year

Basic configurationEngine Yanmar 4TNV88-BSLGWorking deviceStandard bucket rodHydraulic system    Pilot control, load sensingDrive mode Hydraulic driveCab Ordinary cabHeating  & CoolingAir conditionerOther configurationGPS system Dozer blade 1940 Standard bucket(0.11m3)Detailed configurationOverall dimensionL*W*H5165*1620*2450mmOverall width of upper assembly1580mmTail swing radius1400mmOverall height of engine hood1535mmGround clearance of counterweight590mmWheelbase1602mmCrawler pad width300mmMin. ground clearance257mmOverall height of boom1585mmOverall parametersBucket capacity0.11m3Overall operating weight3600kgMax. excavation force32kNSlew speed9.5r/minTraveling speed(low/high)2.8/4.8km/hAverage ground pressure33.5kPaMax. digging radius5300mmMax. digging depth3085mmMax. digging height4800mmMax. dumping height3420mmMin. front slewing radius2040mmEngineModel4TNV88-BSLGTypeFour-stroke, water-cooled,Inlineengine power26.3kwDisplacement2190mlCylinder bore/Stroke88*90mmEmission standardGB 20891-2014(China Phase II)Max. torque143.5N.mMin. fuel-consume ratio244g/kW.hTraveling/swing systemQty. of carrier rollers(single side)1Qty. of track rollers(single side)4Traveling brake typeWet and disc typeSwing modeHydraulic drive internal tooth single-row ball-bearingSwing brake typeWet and disc typeHydraulic systemHydraulic control typePilot proportional control valveHydraulic system typeConstant power load sensitive single pumpMax. flow99L/minMain pump modelA10V045Operating pressure234kgf/cm2Main valve modelSX12Arm cylinder-cylinder bore*diameter of piston rod*stroke1-80*50*670mmBoom cylinder-cylinder bore*diameter of piston rod*stroke1-90*50*559mmBucket cylinder-cylinder bore*diameter of piston rod*stroke1-70*45*490mmFill capacityFuel55LEngine oil7.4LHydraulic oil80LTraveling reducer2*0.6L
